638-044 Series
Manufacturer: EDAC Inc.
Beta
⌘K
D-SUB HIGH DENSITY CONNECTORS VERTICAL HIGH DENSITY D-SUB CONNECTOR
| Part | Dielectric Material | Contact Material | Operating Temperature [Min] | Operating Temperature [Max] | Color | Contact Type | Number of Positions | Number of Rows [custom] | Contact Finish Thickness | Termination | Current Rating (Amps) | Connector Style | Shell Material, Finish | Shell Size, Connector Layout | Features | Material Flammability Rating | Flange Feature | Contact Finish | Mounting Type | Connector Type | Contact Finish Thickness | Contact Finish Thickness | Flange Feature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | Copper Alloy | -55 C | 125 °C | Black | Signal | 44 | 3 | Flash | Solder | 3 A | D-Sub High Density | Nickel Plated Steel | 3 | Shielded | UL94 V-0 | Housing/Shell (Unthreaded) | Gold | Through Hole | Receptacle Female Sockets | |||
 EDAC Inc. | Polyester Thermoplastic | Copper Alloy | -55 C | 85 °C | Black | Signal | 44 | 3 | Solder | 3 A | D-Sub High Density | 3 | Shielded | UL94 V-0 | 4-40 Mating Side Female Screwlock | Gold | Through Hole | Receptacle Female Sockets | 0.38 µm | 15 µin | |||
 EDAC Inc. | Polyester Thermoplastic | Copper Alloy | -55 C | 85 °C | Black | Signal | 44 | 3 | 3 A | D-Sub High Density | 3 | Shielded | UL94 V-0 | Housing/Shell (Unthreaded) | Gold | Free Hanging (In-Line) | Receptacle Female Sockets | 0.76 Ám | 30 Áin | ||||
 EDAC Inc. | Polyester Thermoplastic | Copper Alloy | -55 C | 85 °C | Black | Signal | 44 | 3 | Solder | 3 A | D-Sub High Density | 3 | Shielded | UL94 V-0 | Housing/Shell (Unthreaded) | Gold | Through Hole | Receptacle Female Sockets | 0.76 Ám | 30 Áin | |||
 EDAC Inc. | Polyester Thermoplastic | Copper Alloy | -55 C | 125 °C | Black | Signal | 44 | 3 | 3 A | D-Sub High Density | 3 | Shielded | UL94 V-0 | Housing/Shell (Unthreaded) | Gold | Free Hanging (In-Line) | Receptacle Female Sockets | 0.76 Ám | 30 Áin | ||||
 EDAC Inc. | Polyester Thermoplastic | Copper Alloy | -55 C | 85 °C | Black | Signal | 44 | 3 | Flash | Solder | 3 A | D-Sub High Density | Nickel Plated Steel | 3 | Shielded | UL94 V-0 | 4-40 Mating Side Female Screwlock | Gold | Through Hole | Receptacle Female Sockets | |||
 EDAC Inc. | Polyester Thermoplastic | Copper Alloy | -55 C | 85 °C | Black | Signal | 44 | 3 | Flash | Solder | 3 A | D-Sub High Density | 3 | Shielded | UL94 V-0 | 4-40 | Gold | Through Hole | Receptacle Female Sockets | ||||
 EDAC Inc. | Polyester Thermoplastic | Copper Alloy | -55 C | 85 °C | Black | Signal | 44 | 3 | 3 A | D-Sub High Density | Nickel Plated Steel | 3 | Shielded | UL94 V-0 | Housing/Shell (Unthreaded) | Gold | Free Hanging (In-Line) | Receptacle Female Sockets | 0.76 Ám | 30 Áin | |||
 EDAC Inc. | Polyester Thermoplastic | Copper Alloy | -55 C | 125 °C | Black | Signal | 44 | 3 | Flash | 3 A | D-Sub High Density | 3 | Board Lock Shielded | UL94 V-0 | Housing/Shell | Gold | Free Hanging (In-Line) | Receptacle Female Sockets | 4-40 | ||||
 EDAC Inc. | Polyester Thermoplastic | Copper Alloy | -55 C | 85 °C | Black | Signal | 44 | 3 | Solder | 3 A | D-Sub High Density | Nickel Plated Steel | 3 | Board Lock Shielded | UL94 V-0 | 4-40 Mating Side Female Screwlock | Gold | Through Hole | Receptacle Female Sockets | 0.38 µm | 15 µin |
