TRI 15 Series
Manufacturer: Traco Power
Beta
⌘K
ISOLATED DC/DC CONVERTERS - THROUGH HOLE 18-36VIN 24V 625MA 15W ISO REG 2X1
| Part | Type | Voltage - Isolation | Voltage - Input (Max) [Max] | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [x] | Size / Dimension [z] | Current - Output (Max) [Max] | Number of Outputs | Efficiency | Voltage - Output 1 | Approval Agency | Operating Temperature [Max] | Operating Temperature [Min] | Power (Watts) | Voltage - Input (Min) [Min] | Applications | Mounting Type | Package / Case | Current - Output (Max) | Voltage - Output 2 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Traco Power | Isolated Module | 8 kV | 36 V | 25.4 mm | 0.47 " | 1 " | 50.8 mm | 2 in | 12 mm | 625 mA | 1 | 90 % | 24 V | CB cURus | 85 °C | -40 C | 15 W | 18 V | ITE (Commercial) | Through Hole | 5-DIP Module 4 Leads | ||
 Traco Power | Isolated Module | 8 kV | 36 V | 25.4 mm | 0.47 " | 1 " | 50.8 mm | 2 in | 12 mm | 2 | 89 % | 15 V | CB cURus | 85 °C | -40 C | 15 W | 18 V | ITE (Commercial) | Through Hole | 5-DIP Module | 500 mA | -15 V | |
 Traco Power | Isolated Module | 8 kV | 36 V | 25.4 mm | 0.47 " | 1 " | 50.8 mm | 2 in | 12 mm | 1.25 A | 1 | 88 % | 12 V | CB cURus | 85 °C | -40 C | 15 W | 18 V | ITE (Commercial) | Through Hole | 5-DIP Module 4 Leads |
