BXRC-57 Series

Manufacturer: BRIDGELUX

Catalog

Catalog

LED COB VERO 18 WHT RND 5700K

...

Part	Lumens/Watt @ Current - Test	Luminous Flux @ Current/Temperature	Current - Test	Current - Max [Max]	Configuration	Type	Viewing Angle	CRI (Color Rendering Index)	Temperature - Test	Voltage - Forward (Vf) (Typ)	Color	Height [z]	CCT (K)	CCT (K)	Light Emitting Surface (LES) [diameter]	Size / Dimension [diameter]	Lens Type	Height	Features
BRIDGELUX BXRC-57C4001-B-73	157 lm/W 163 lm/W	4789 lm 4965 lm	900 mA	1.8 A	Round	Chip On Board (COB)	120 °	70	85 °C	33.9 V	Cool White	1.9 mm	5700 K	3-Step MacAdam Ellipse	18.4 mm	36.2 mm	Flat
BRIDGELUX BXRC-57C1001-C-74-SE	153 lm/W	1860 lm	360 mA	720 mA	Round	Chip On Board (COB)	120 °	70	85 °C	33.8 V	Cool White	3.6 mm	5700 K		9.9 mm	30.8 mm	Flat
BRIDGELUX BXRC-57C1001-C-83	188 lm/W	1728 lm	300 mA	1 A	Starboard	Chip On Board (COB)	120 °	70	25 °C	30.7 V	Cool White		5700 K	3-Step MacAdam Ellipse	10 mm	20 mm	Flat	1.8 mm
BRIDGELUX BXRC-57C4001-C-73	157 lm/W 163 lm/W	6227 lm 6454 lm	1.17 A	2.34 A	Round	Chip On Board (COB)	120 °	70	85 °C	33.9 V	Cool White	1.9 mm	5700 K	3-Step MacAdam Ellipse	18.4 mm	36.2 mm	Flat
BRIDGELUX BXRC-57E2001-C-84-SE	175 lm/W	2920 lm	500 mA	1.75 A	Round	Chip On Board (COB)	120 °	80	25 °C	33.4 V	Cool White	3.6 mm	5700 K		13.3 mm	36.2 mm	Flat
BRIDGELUX BXRC-57E2001-B-74-SE	153 lm/W	2340 lm	450 mA	900 mA	Round	Chip On Board (COB)	120 °	80	85 °C	33.9 V	Cool White	3.6 mm	5700 K		13.4 mm	36.2 mm	Flat
BRIDGELUX BXRC-57E1001-D-74	164 lm/W	1492 lm	350 mA	700 mA	Starboard	Chip On Board (COB)	120 °	80	25 °C	26 V	Cool White	1.9 mm	5700 K		9.9 mm	20 mm	Flat		With Connector
BRIDGELUX BXRC-57C2001-C-74	156 lm/W	3353 lm	630 mA	1.26 A	Round	Chip On Board (COB)	120 °	70	85 °C	34.1 V	Cool White	1.9 mm	5700 K		13.2 mm	36.2 mm	Flat		With Connector
BRIDGELUX BXRC-57C2001-C-73-SE	160 lm/W	3414 lm	630 mA	1.26 A	Round	Chip On Board (COB)	120 °	70	85 °C	33.9 V	Cool White	3.6 mm	5700 K	3-Step MacAdam Ellipse	13.4 mm	36.2 mm	Flat
BRIDGELUX BXRC-57C1001-D-73-SE	153 lm/W	1351 lm	350 mA	700 mA	Round	Chip On Board (COB)	120 °	70	85 °C	25.3 V	Cool White	3.6 mm	5700 K	3-Step MacAdam Ellipse	9.9 mm	30.8 mm	Flat
