AMEL60 Series

Manufacturer: aimtec

Catalog

AC/DC CONVERTER 48V 60W

Part	Weight [custom]	Weight [custom]	Load Regulation	Line Regulation	Current - Output (Max) [Max]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Power (Watts)	Package / Case	Voltage - Input [Min]	Voltage - Input [Max]	Efficiency	Mounting Type	Voltage - Output 1	Type	Applications	Number of Outputs	Features	Current - Output (Max)
aimtec AMEL60-48SJZ	210 g	0.463 lb	±1%	0.5 %	1.25 A	1.16 in	3.43 "	29.5 mm	2.05 in	52 mm	87 mm	60 W	4-DIP Module	85 VAC 100 V	264 VAC 370 VDC	90 %	Through Hole	48 V	Enclosed	ITE (Commercial)	1	Universal Input
aimtec AMEL60-24SJZ	210 g	0.463 lb	±1%	0.5 %	2.5 A	1.16 in	3.43 "	29.5 mm	2.05 in	52 mm	87 mm	60 W	4-DIP Module	85 VAC 100 V	264 VAC 370 VDC	89 %	Through Hole	24 V	Enclosed	ITE (Commercial)	1	Universal Input
aimtec AMEL60-15SJZ	210 g	0.463 lb	±1%	0.5 %	4 A	1.16 in	3.43 "	29.5 mm	2.05 in	52 mm	87 mm	60 W	4-DIP Module	85 VAC 100 V	264 VAC 370 VDC	88 %	Through Hole	15 V	Enclosed	ITE (Commercial)	1	Universal Input
aimtec AMEL60-12SJZ	210 g	0.463 lb	±1%	0.5 %		1.16 in	3.43 "	29.5 mm	2.05 in	52 mm	87 mm	60 W	4-DIP Module	85 VAC 100 V	264 VAC 370 VDC	87 %	Through Hole	12 V	Enclosed	ITE (Commercial)	1	Universal Input	5 A
