GRN-80 Series

Catalog

GRN-80-1006 OVP CHCO

Part	Features	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [y]	Operating Temperature [Max]	Approval Agency	Applications	Voltage - Output 1	Number of Outputs	Current - Output 1	Power (Watts)	Standard Number	Efficiency	Type	Mounting Type	Voltage - Output 2	Current - Output 2	Voltage - Output 3	Current - Output 3	Current - Output 4	Voltage - Output 4
Integrated Power Designs 1011367CHCO	Adjustable Output Remote Sense Universal Input	4.5 in	69.9 mm	114.3 mm	32.5 mm	1.28 "	2.75 in	70 °C	CE cURus TUV UKCA	ITE (Commercial) Medical	28 V	1	2.9 A	80 W	60601-1; 62368-1	87 %	Enclosed	Chassis Mount
Integrated Power Designs 1011280CH	Adjustable Output Remote Sense Universal Input	4.5 in	69.9 mm	114.3 mm	32.5 mm	1.28 "	2.75 in	70 °C	CE cURus TUV UKCA	ITE (Commercial) Medical	15 V	1	5.3 A	80 W	60601-1; 62368-1	87 %	Chassis	Chassis Mount
Integrated Power Designs 1011362CH	Adjustable Output Remote Sense Universal Input	4.5 in	69.9 mm	114.3 mm	32.5 mm	1.28 "	2.75 in	70 °C	CE cURus TUV UKCA	ITE (Commercial) Medical	3.3 V	1	16 A	53 W	60601-1; 62368-1		Chassis	Chassis Mount
Integrated Power Designs 1011390CHCO	Adjustable Output Remote Sense Universal Input	5.25 in	82.6 mm	133.4 mm	32.5 mm	1.28 "	3.25 "	70 °C	CE cURus TUV UKCA	ITE (Commercial) Medical	15 V	2	3 A	80 W	60601-1; 62368-1	88 %	Enclosed	Chassis Mount	-15 V	3 A
Integrated Power Designs 1011259CHCO	Adjustable Output Remote Sense Universal Input	5.25 in	82.6 mm	133.4 mm	32.5 mm	1.28 "	3.25 "	70 °C	CE cURus TUV UKCA	ITE (Commercial) Medical	12 V	2	4 A	80 W	60601-1; 62368-1	88 %	Enclosed	Chassis Mount	-12 V	4 A
Integrated Power Designs 1011279CH	Adjustable Output Remote Sense Universal Input	4.5 in	69.9 mm	114.3 mm	32.5 mm	1.28 "	2.75 in	70 °C	CE cURus TUV UKCA	ITE (Commercial) Medical	12 V	1	6.7 A	80 W	60601-1; 62368-1	87 %	Chassis	Chassis Mount
Integrated Power Designs 1011256CHCO	Adjustable Output Remote Sense Universal Input	5.25 in	82.6 mm	133.4 mm	32.5 mm	1.28 "	3.25 "	70 °C	CE cURus TUV UKCA	ITE (Commercial) Medical	5 V	3	8 A	80 W	60601-1; 62368-1	88 %	Enclosed	Chassis Mount	15 V	2 A	-15 V	2 A
Integrated Power Designs 1011281CHCO	Adjustable Output Remote Sense Universal Input	4.5 in	69.9 mm	114.3 mm	32.5 mm	1.28 "	2.75 in	70 °C	CE cURus TUV UKCA	ITE (Commercial) Medical	24 V	1	3.3 A	80 W	60601-1; 62368-1	87 %	Enclosed	Chassis Mount
Integrated Power Designs 1011252CHCO	Adjustable Output Remote Sense Universal Input	5.25 in	82.6 mm	133.4 mm	32.5 mm	1.28 "	3.25 "	70 °C	CE cURus TUV UKCA	ITE (Commercial) Medical	5 V	4	8 A	80 W	60601-1; 62368-1	88 %	Enclosed	Chassis Mount	-5 V	5 A	12 V	1.5 A	1.5 A	-12 V
Integrated Power Designs 1011367CH	Adjustable Output Remote Sense Universal Input	4.5 in	69.9 mm	114.3 mm	32.5 mm	1.28 "	2.75 in	70 °C	CE cURus TUV UKCA	ITE (Commercial) Medical	28 V	1	2.9 A	80 W	60601-1; 62368-1	87 %	Chassis	Chassis Mount
