DF17 Series

Catalog

BOARD TO BOARD & MEZZANINE CONNECTORS 20P F RECEPTACLE STRAIGHT SMT GLD PLT

Part	Mated Stacking Heights	Connector Type	Number of Rows [custom]	Contact Finish	Pitch	Pitch	Number of Positions	Features	Mounting Type	Height Above Board [z]	Height Above Board [z]	Height Above Board	Height Above Board	Contact Finish Thickness	Contact Finish Thickness
Hirose Electric Co Ltd DF17B(3.0)-20DS-0.5V(57)	5 mm 5.5 mm 7 mm	Receptacle Center Strip Contacts	2	Gold	0.02 "	0.5 mm	20	Solder Retention	Surface Mount
Hirose Electric Co Ltd DF17B(1.0H)-26DP-0.5V(57)	4 mm	Header Outer Shroud Contacts	2	Gold	0.02 "	0.5 mm	26	Solder Retention	Surface Mount	3.3 mm	0.13 in
Hirose Electric Co Ltd DF17A(4.0)-40DP-0.5V(57)	7 mm 8 mm	Header Outer Shroud Contacts	2	Gold	0.02 "	0.5 mm	40	Board Guide	Surface Mount	6.3 mm	0.248 in
Hirose Electric Co Ltd DF17(2.0)-60DP-0.5V(57)	5 mm 6 mm	Header Outer Shroud Contacts	2	Gold	0.02 "	0.5 mm	60	Board Guide Solder Retention	Surface Mount			0.169 in	4.3 mm
Hirose Electric Co Ltd DF17B(3.0)-60DS-0.5V(57)	5 mm 5.5 mm 7 mm	Receptacle Center Strip Contacts	2	Gold	0.02 "	0.5 mm	60	Solder Retention	Surface Mount
Hirose Electric Co Ltd DF17B(3.0H)-60DS-0.5V(57)	4 mm	Receptacle Center Strip Contacts	2	Gold	0.02 "	0.5 mm	60	Solder Retention	Surface Mount	3 mm	0.118 in
Hirose Electric Co Ltd DF17C(2.0)-80DP-0.5V(57)	5 mm 6 mm	Header Outer Shroud Contacts	2	Gold	0.02 "	0.5 mm	80	Solder Retention	Surface Mount			0.169 in	4.3 mm	0.25 Ám	10 Áin
Hirose Electric Co Ltd DF17A(4.0)-40DS-0.5V(57)	6 mm 6.5 mm 8 mm	Receptacle Center Strip Contacts	2	Gold	0.02 "	0.5 mm	40	Board Guide	Surface Mount	4.5 mm	0.177 in
Hirose Electric Co Ltd DF17B(3.0H)-26DS-0.5V(57)	4 mm	Receptacle Center Strip Contacts	2	Gold	0.02 "	0.5 mm	26	Solder Retention	Surface Mount	3 mm	0.118 in
Hirose Electric Co Ltd DF17A(4.0)-80DS-0.5V(57)	6 mm 6.5 mm 8 mm	Receptacle Center Strip Contacts	2	Gold	0.02 "	0.5 mm	80	Board Guide	Surface Mount	4.5 mm	0.177 in
