DSC1124 Series

Catalog

MEMS OSC, HCSL, 156.25MHZ, 50PPM, 2.5-3.3V, -40 TO 85C, 3.2 X 2.5MM 6 VDFN 3.2X2.5X0.9MM T/R ROHS COMPLIANT: YES

Part	Operating Temperature [Max]	Operating Temperature [Min]	Frequency Stability	Frequency	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Type	Current - Supply (Max) [Max]	Base Resonator	Output	Function	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Current - Supply (Disable) (Max) [Max]	Mounting Type	Package / Case	Voltage - Supply [Max]	Voltage - Supply [Min]
Microchip Technology DSC1124CI1-156.2500TA	85 °C	-40 °C	50 ppm	156.25 MHz	3.2 mm	2.5 mm	0.126 in	0.098 in	XO (Standard)	42 mA	MEMS	HCSL	Enable/Disable	0.035 "	0.9 mm	22 mA	Surface Mount	6-SMD No Lead	3.6 V	2.25 V
Microchip Technology DSC1124BI5-148.3516T	85 °C	-40 °C	10 ppm	148.3516 MHz	5 mm	3.2 mm	0.197 in	0.126 "	XO (Standard)	42 mA	MEMS	HCSL	Enable/Disable	0.035 "	0.9 mm	22 mA	Surface Mount	6-VDFN	3.6 V	2.25 V
Microchip Technology DSC1124DI1-100.0000	85 °C	-40 °C	50 ppm	100 MHz	2.5 mm	2 mm	0.098 "	0.079 in	XO (Standard)	42 mA	MEMS	HCSL	Enable/Disable	0.035 "	0.9 mm	22 mA	Surface Mount	6-VDFN	3.6 V	2.25 V
Microchip Technology DSC1124CI1-156.2500	85 °C	-40 °C	50 ppm	156.25 MHz	3.2 mm	2.5 mm	0.126 in	0.098 in	XO (Standard)	42 mA	MEMS	HCSL	Enable/Disable	0.035 "	0.9 mm	22 mA	Surface Mount	6-SMD No Lead 6-VDFN	3.6 V	2.25 V
Microchip Technology DSC1124NI1-156.2500	85 °C	-40 °C	50 ppm	156.25 MHz	7 mm	5 mm	0.276 "	0.197 "	XO (Standard)	42 mA	MEMS	HCSL	Enable/Disable	0.035 "	0.9 mm	22 mA	Surface Mount	6-SMD No Lead	3.6 V	2.25 V
Microchip Technology DSC1124BI2-125.0000	85 °C	-40 °C	25 ppm	125 MHz	5 mm	3.2 mm	0.197 in	0.126 "	XO (Standard)	42 mA	MEMS	HCSL	Enable/Disable	0.035 "	0.9 mm	22 mA	Surface Mount	6-VDFN	3.6 V	2.25 V
Microchip Technology DSC1124CI2-100.0000	85 °C	-40 °C	25 ppm	100 MHz	3.2 mm	2.5 mm	0.126 in	0.098 in	XO (Standard)	42 mA	MEMS	HCSL	Enable/Disable	0.035 "	0.9 mm	22 mA	Surface Mount	6-SMD No Lead 6-VDFN	3.6 V	2.25 V
Microchip Technology DSC1124BL5-100.0000	105 ░C	-40 °C	10 ppm	100 MHz	5 mm	3.2 mm	0.197 in	0.126 "	XO (Standard)	42 mA	MEMS	HCSL	Enable/Disable	0.035 "	0.9 mm	22 mA	Surface Mount	6-VDFN	3.6 V	2.25 V
Microchip Technology DSC1124CE1-050.0000	70 °C	-20 C	50 ppm	50 MHz	3.2 mm	2.5 mm	0.126 in	0.098 in	XO (Standard)	42 mA	MEMS	HCSL	Enable/Disable	0.035 "	0.9 mm	22 mA	Surface Mount	6-SMD No Lead	3.6 V	2.25 V
Microchip Technology DSC1124DI5-190.9750T	85 °C	-40 °C	10 ppm	190.975 MHz	2.5 mm	2 mm	0.098 "	0.079 in	XO (Standard)	42 mA	MEMS	HCSL	Enable/Disable	0.035 "	0.9 mm	22 mA	Surface Mount	6-VDFN	3.6 V	2.25 V
