Z01 Series

Catalog

TRIAC SENS GATE 600V 1A TO92-3

Part	Mounting Type	Configuration	Current - Non Rep. Surge (Itsm)	Current - Non Rep. Surge Type	Current - Non Rep. Surge Frequencies	Voltage - Gate Trigger (Vgt) (Max)	Triac Type	Voltage - Off State	Operating Temperature (Max)	Operating Temperature (Min)	Package / Case	Package Name	Current - Hold (Ih) (Max)	Current - On State (It (RMS)) (Max)	Current - Gate Trigger (Igt) (Max)
STMicroelectronics Z0109MA 1AA2	Through Hole	Single	8 A 8.5 A	Itsm	50Hz 60Hz	1.3 V	Logic - Sensitive Gate	600 V	125 °C	-40 °C	TO-226-3 TO-92-3 (TO-226AA)	TO-92-3	10 mA	1 A	10 mA
STMicroelectronics Z0103MN 6AA4	Surface Mount	Single	8 A 8.5 A	Itsm	50Hz 60Hz	1.3 V	Logic - Sensitive Gate	600 V	125 °C	-40 °C	TO-261-4 TO-261AA	SOT-223	7 mA	1 A	3 mA
STMicroelectronics Z0107NN 5AA4	Surface Mount	Single	8 A 8.5 A	Itsm	50Hz 60Hz	1.3 V	Logic - Sensitive Gate	800 V	125 °C	-40 °C	TO-261-4 TO-261AA	SOT-223	10 mA	1 A	5 mA
STMicroelectronics Z0107MUF	Surface Mount	Single	8 A 8.5 A	Itsm	50Hz 60Hz	1.3 V	Logic - Sensitive Gate	600 V	125 °C	-40 °C	3-SMB Flat Leads	SMBflat-3L	10 mA	1 A	5 mA
STMicroelectronics Z0103MUF	Surface Mount	Single	8 A 8.5 A	Itsm	50Hz 60Hz	1.3 V	Logic - Sensitive Gate	600 V	125 °C	-40 °C	3-SMB Flat Leads	SMBflat-3L	7 mA	1 A	3 mA
STMicroelectronics Z0103MA 1AA2	Through Hole	Single	8 A 8.5 A	Itsm	50Hz 60Hz	1.3 V	Logic - Sensitive Gate	600 V	125 °C	-40 °C	TO-226-3 TO-92-3 (TO-226AA)	TO-92-3	7 mA	1 A	3 mA
STMicroelectronics Z0109NA 2AL2	Through Hole	Single	8 A 8.5 A	Itsm	50Hz 60Hz	1.3 V	Logic - Sensitive Gate	800 V	125 °C	-40 °C	TO-226-3 TO-92-3 (TO-226AA) Formed Leads	TO-92-3	10 mA	1 A	10 mA
STMicroelectronics Z0103MA 5AL2	Through Hole	Single	8 A 8.5 A	Itsm	50Hz 60Hz	1.3 V	Logic - Sensitive Gate	600 V	125 °C	-40 °C	TO-226-3 TO-92-3 (TO-226AA) Formed Leads	TO-92-3	7 mA	1 A	3 mA
STMicroelectronics Z0109MN 5AA4	Surface Mount	Single	8 A 8.5 A	Itsm	50Hz 60Hz	1.3 V	Logic - Sensitive Gate	600 V	125 °C	-40 °C	TO-261-4 TO-261AA	SOT-223	10 mA	1 A	10 mA
STMicroelectronics Z0107MN 5AA4	Surface Mount	Single	8 A 8.5 A	Itsm	50Hz 60Hz	1.3 V	Logic - Sensitive Gate	600 V	125 °C	-40 °C	TO-261-4 TO-261AA	SOT-223	10 mA	1 A	5 mA
