1825139 Series

Manufacturer: TE Connectivity Raychem Cable Protection

Catalog

SWITCH TOGGLE SP3T 5A 120V

Part	Panel Cutout Dimensions [diameter]	Voltage Rating - DC	Actuator Material	Illumination	Circuit	Voltage Rating - AC	Actuator Length [x]	Current Rating (Amps)	Switch Function	Termination Style	Bushing Thread	Features	Actuator Type	Electrical Life	Operating Temperature [Min]	Operating Temperature [Max]	Mounting Type
TE Connectivity Raychem Cable Protection 3-1825139-4	0.25 in	28 V	Brass Nickel Plated	Non-Illuminated	SP3T	120 V	12.19 mm	5 A	On-On-On	Solder Lug	1/4-40	Jumper needed to achieve triple throw	Standard Round	6000 Cycles	-30 ░C	85 °C
TE Connectivity Raychem Cable Protection 1-1825139-5		20 V	Brass Nickel Plated	Non-Illuminated	DPDT	20 V	12.19 mm	0.4 VA	Mom-Off-Mom	PC Pin	Unthreaded	Epoxy Sealed Terminals	Standard Round	6000 Cycles	-30 ░C	85 °C	Through Hole Right Angle
TE Connectivity Raychem Cable Protection 2-1825139-0	12 mm	28 V	Brass Nickel Plated	Non-Illuminated	DPDT	120 V	17.45 mm	5 A	Mom-Off-Mom	Solder Lug	15/32-32	Epoxy Sealed Terminals	Standard Round	6000 Cycles	-30 ░C	85 °C
TE Connectivity Raychem Cable Protection 1-1825139-9	12 mm	28 V	Brass Nickel Plated	Non-Illuminated	DPDT	120 V	12.37 mm	5 A	Mom-Off-Mom	Solder Lug	15/32-32	Epoxy Sealed Terminals	Standard Round	6000 Cycles	-30 ░C	85 °C
TE Connectivity Raychem Cable Protection 3-1825139-5	0.25 in	28 V	Brass Nickel Plated	Non-Illuminated	SP3T	120 V	10.41 mm	5 A	On-On-On	Solder Lug	1/4-40	Jumper needed to achieve triple throw	Standard Round	6000 Cycles	-30 ░C	85 °C
TE Connectivity Raychem Cable Protection 1825139-4	0.25 in	28 V	Brass Nickel Plated	Non-Illuminated	DPDT	120 V	12.29 mm	5 A	On-Off-On	Solder Lug	1/4-40	Epoxy Sealed Terminals	Flatted	6000 Cycles	-30 ░C	85 °C
TE Connectivity Raychem Cable Protection 1825139-1	0.25 in	28 V	Brass Nickel Plated	Non-Illuminated	DPDT	120 V	16.51 mm	5 A	On-Off-On	Solder Lug	1/4-40	Epoxy Sealed Terminals	Locking Lever	6000 Cycles	-30 ░C	85 °C
TE Connectivity Raychem Cable Protection 1825139-7	0.25 in	28 V	Brass Nickel Plated	Non-Illuminated	DPDT	120 V	12.19 mm	5 A	On-Off-On	Solder Lug	1/4-40	Epoxy Sealed Terminals	Standard Round	6000 Cycles	-30 ░C	85 °C
TE Connectivity Raychem Cable Protection 1-1825139-0	0.25 in	28 V	Brass Nickel Plated	Non-Illuminated	DPDT	120 V	10.41 mm	5 A	On-Off-On	Solder Lug	1/4-40	Epoxy Sealed Terminals	Standard Round	6000 Cycles	-30 ░C	85 °C
TE Connectivity Raychem Cable Protection 1-1825139-6	0.25 in	20 V	Brass Nickel Plated	Non-Illuminated	DPDT	20 V	10.41 mm	0.4 VA	Mom-Off-Mom	PC Pin	1/4-40	Epoxy Sealed Terminals	Standard Round	6000 Cycles	-30 ░C	85 °C
