A3C-20P Series

Catalog

CONN HEADER VERT 20POS 2MM

Part	Mated Stacking Heights	Contact Finish Thickness - Post	Contact Length - Post	Contact Length - Post	Style	Contact Type	Connector Type	Fastening Type	Voltage Rating	Contact Material	Contact Length - Mating	Contact Length - Mating	Insulation Color	Operating Temperature [Min]	Operating Temperature [Max]	Number of Rows [custom]	Shrouding	Termination	Contact Finish - Post	Number of Positions	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Overall Contact Length	Overall Contact Length	Row Spacing - Mating	Row Spacing - Mating	Insulation Material	Insulation Height [z]	Insulation Height [z]	Contact Shape	Number of Positions Loaded	Mounting Type	Pitch - Mating	Pitch - Mating	Material Flammability Rating	Contact Finish - Mating
Hirose Electric Co Ltd A3C-20P-2DSA	5.1 mm 7.9 mm	Flash	2.6 mm	0.102 in	Board to Board Cable	Male Pin	Header	Push-Pull	200 V	Brass	3.5 mm	0.138 in	Black	-55 C	85 °C	2	Unshrouded	Solder	Gold	20	8 µin	0.203 µm	7 mm	0.276 in	2 mm	0.079 in	Nylon Polyamide (PA)	0.9 mm	0.035 in	Square	All	Through Hole	0.079 "	2 mm	UL94 V-0	Gold
