845-116 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FML 116POS 0.100
| Part | Termination Rows [custom] | Material - Insulation | Gender | Mounting Type | Contact Finish Thickness | Contact Finish Thickness | Read Out | Contact Finish | Number of Positions | Pitch | Pitch | Contact Material | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Contact Type | Number of Positions/Bay/Row | Termination | Color | Number of Rows [custom] | Card Thickness [Max] | Card Thickness [Min] | Card Type | Operating Temperature [Max] | Operating Temperature [Min] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Female | Through Hole | 0.25 Ám | 10 Áin | Dual | Gold | 116 | 0.1 " | 2.54 mm | Copper Alloy | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | Cantilever | 58 | Wire Wrap | Green | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | 125 °C | -40 C | |
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Female | Board Edge Straddle Mount | 0.25 Ám | 10 Áin | Dual | Gold | 116 | 0.1 " | 2.54 mm | Copper Alloy | Side Mount Opening Unthreaded | 3.25 mm | 0.128 " | Cantilever | 58 | Solder | Green | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | 125 °C | -40 C | Card Extender |
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Female | Through Hole | 0.25 Ám | 10 Áin | Dual | Gold | 116 | 0.1 " | 2.54 mm | Copper Alloy | Floating Bobbin Top Mount Opening | 2.95 mm | 0.116 " | Cantilever | 58 | Solder | Green | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | 125 °C | -40 C | |
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Female | Through Hole | 0.25 Ám | 10 Áin | Dual | Gold | 116 | 0.1 " | 2.54 mm | Copper Alloy | Floating Bobbin Top Mount Opening | 2.95 mm | 0.116 " | Cantilever | 58 | Wire Wrap | Green | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | 125 °C | -40 C | |
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Female | Board Edge Straddle Mount | 0.25 Ám | 10 Áin | Dual | Gold | 116 | 0.1 " | 2.54 mm | Copper Alloy | 4-40 Flush Mount Threaded Insert Top Opening | Cantilever | 58 | Solder | Green | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | 125 °C | -40 C | Card Extender | ||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Female | Board Edge Straddle Mount | 0.25 Ám | 10 Áin | Dual | Gold | 116 | 0.1 " | 2.54 mm | Copper Alloy | M3 Threaded Insert Top Mount Opening | Cantilever | 58 | Solder | Green | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | 125 °C | -40 C | Card Extender | ||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Female | Through Hole | 0.25 Ám | 10 Áin | Dual | Gold | 116 | 0.1 " | 2.54 mm | Copper Alloy | M3 Threaded Insert Top Mount Opening | Cantilever | 58 | Wire Wrap | Green | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | 125 °C | -40 C | |||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Female | Board Edge Straddle Mount | 0.25 Ám | 10 Áin | Dual | Gold | 116 | 0.1 " | 2.54 mm | Copper Alloy | Flush Mount Top Opening Unthreaded | 3.96 mm | 0.156 " | Cantilever | 58 | Solder | Green | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | 125 °C | -40 C | Card Extender |
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Female | Board Edge Straddle Mount | 0.25 Ám | 10 Áin | Dual | Gold | 116 | 0.1 " | 2.54 mm | Copper Alloy | 3.96 mm | 0.156 " | Cantilever | 58 | Solder | Green | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | 125 °C | -40 C | Card Extender | |
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Female | Through Hole | 0.25 Ám | 10 Áin | Dual | Gold | 116 | 0.1 " | 2.54 mm | Copper Alloy | 3.25 mm | 0.128 " | Cantilever | 58 | Solder | Green | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | 125 °C | -40 C |
