887-036 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 36POS 0.156
| Part | Material - Insulation | Termination Rows | Number of Positions | Contact Material | Pitch | Pitch | Card Type | Contact Finish | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Gender | Number of Positions/Bay/Row | Color | Mounting Type | Contact Type | Termination | Operating Temperature [Max] | Operating Temperature [Min] | Card Thickness [Max] | Card Thickness [Min] | Number of Rows | Read Out | Contact Finish Thickness | Contact Finish Thickness | Termination Rows [custom] | Number of Rows [custom] | Number of Positions/Bay/Row [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 36 | Copper Alloy | 3.96 mm | 0.156 in | Non Specified - Single Edge | Gold | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | Female | 36 | Black | Through Hole | Cantilever | Solder | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | Single | 0.25 Ám | 10 Áin | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 36 | Copper Alloy | 3.96 mm | 0.156 in | Non Specified - Single Edge | Gold | M3 Threaded Insert Top Mount Opening | Female | 36 | Black | Through Hole | Cantilever | Wire Wrap | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | Single | 0.25 Ám | 10 Áin | |||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 36 | Copper Alloy | 3.96 mm | 0.156 in | Non Specified - Single Edge | Gold | Floating Bobbin Top Mount Opening | 2.95 mm | 0.116 " | Female | 36 | Black | Through Hole | Cantilever | Solder | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | Single | 0.25 Ám | 10 Áin | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 36 | Copper Alloy | 3.96 mm | 0.156 in | Non Specified - Dual Edge | Gold | Side Mount Opening Unthreaded | 3.25 mm | 0.128 " | Female | Black | Through Hole | Cantilever | Solder | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | 0.25 Ám | 10 Áin | 2 | 2 | 18 | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 36 | Copper Alloy | 3.96 mm | 0.156 in | Non Specified - Dual Edge | Gold | Flush Mount Side Opening Unthreaded | 3.25 mm | 0.128 " | Female | Black | Through Hole | Cantilever | Wire Wrap | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | 0.25 Ám | 10 Áin | 2 | 2 | 18 | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 36 | Copper Alloy | 3.96 mm | 0.156 in | Non Specified - Single Edge | Gold | Floating Bobbin Flush Mount | 2.95 mm | 0.116 " | Female | 36 | Black | Through Hole | Cantilever | Solder | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | Single | 0.25 Ám | 10 Áin | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 36 | Copper Alloy | 3.96 mm | 0.156 in | Non Specified - Dual Edge | Gold | 3.96 mm | 0.156 " | Female | Black | Through Hole | Cantilever | Solder | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | 0.25 Ám | 10 Áin | 2 | 2 | 18 | ||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 36 | Copper Alloy | 3.96 mm | 0.156 in | Non Specified - Single Edge | Gold | Side Mount Opening Unthreaded | 3.25 mm | 0.128 " | Female | 36 | Black | Through Hole | Cantilever | Solder | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | Single | 0.25 Ám | 10 Áin | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 36 | Copper Alloy | 3.96 mm | 0.156 in | Non Specified - Single Edge | Gold | M3 Threaded Insert Top Mount Opening | Female | 36 | Black | Through Hole | Cantilever | Solder | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | Single | 0.25 Ám | 10 Áin | |||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 36 | Copper Alloy | 3.96 mm | 0.156 in | Non Specified - Single Edge | Gold | 3.25 mm | 0.128 " | Female | 36 | Black | Through Hole | Cantilever | Wire Wrap | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | Single | 0.25 Ám | 10 Áin |
