H.FL-R Series
Manufacturer: Hirose Electric Co Ltd
Beta
⌘K
CONN H.FL RCPT STR 50 OHM SMD
| Part | Body Finish | Operating Temperature [Max] | Operating Temperature [Min] | Dielectric Material | Center Contact Plating | Body Material | Mating Cycles | Shield Termination | Fastening Type | Frequency - Max [Max] | Connector Style | Center Contact Material | Contact Termination | Impedance | Connector Type | Housing Color | Number of Ports | Mounting Type | Mounting Feature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Hirose Electric Co Ltd | Silver | 90 °C | -40 C | Liquid Crystal Polymer (LCP) | Gold | Phosphor Bronze | 50 | Solder | Snap-On | 3 GHz | H.FL | Phosphor Bronze | Solder | 50 Ohms | Receptacle Male Pin | Black | 1 | Surface Mount | |
 Hirose Electric Co Ltd | Silver | 90 °C | -40 C | Liquid Crystal Polymer (LCP) | Gold | Phosphor Bronze | 50 | Solder | Snap-On | 3 GHz | H.FL | Brass | Solder | 50 Ohms | Receptacle Male Pin | Black | 1 | Surface Mount | |
Hirose Electric Co Ltd | Silver | 90 °C | -40 C | Liquid Crystal Polymer (LCP) | Gold | Phosphor Bronze | 50 | Solder | Snap-On | 3 GHz | H.FL | Brass | Solder | 50 Ohms | Receptacle Male Pin | Black | 1 | Surface Mount | |
 Hirose Electric Co Ltd | Nickel | 90 °C | -40 C | Polytetrafluoroethylene (PTFE) | Gold | Stainless Steel | 1000 | Solder | Snap-On | 3 GHz | H.FL | Beryllium Copper | Solder Cup | 50 Ohms | Receptacle Male Pin | Silver | 1 | Panel Mount | Bulkhead |
