M80-5000000M1 Series
Manufacturer: Harwin Inc.
Beta
⌘K
PIN HEADER, PCB HEADER, WIRE-TO-BOARD, 4 MM, 1 ROWS, 4 CONTACTS, THROUGH HOLE
| Part | Mated Stacking Heights | Voltage Rating | Number of Rows | Termination | Fastening Type | Contact Finish - Mating | Contact Shape | Insulation Material | Connector Type | Insulation Height | Insulation Height | Pitch - Mating | Pitch - Mating | Mounting Type | Operating Temperature [Min] | Operating Temperature [Max] | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Contact Material | Number of Positions Loaded | Material Flammability Rating | Contact Length - Post | Contact Length - Post | Current Rating (Amps) | Number of Positions | Contact Type | Style | Insulation Color | Features | Shrouding |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Harwin Inc. | 7.3 mm 9.75 mm | 800 V | 1 | Solder | Threaded | Gold | Circular | Polyphenylene Sulfide (PPS) Glass Filled | Header | 5.6 mm | 0.22 in | 4 mm | 0.157 in | Through Hole | -55 C | 125 °C | 0.25 µm | 10 µin | Copper Alloy | All | UL94 V-0 | 0.138 in | 3.5 mm | 20 A | 4 | Male Pin Power | Board to Cable/Wire | Black | Keying Slot Mating Flange | Shrouded - 4 Wall |
 Harwin Inc. | 7.3 mm 9.75 mm | 800 V | 1 | Solder | Threaded | Gold | Circular | Polyphenylene Sulfide (PPS) Glass Filled | Header | 5.6 mm | 0.22 in | 4 mm | 0.157 in | Through Hole | -55 C | 125 °C | 0.76 Ám | 30 Áin | Copper Alloy | All | UL94 V-0 | 0.138 in | 3.5 mm | 40 A | 8 | Male Pin Power | Board to Cable/Wire | Black | Keying Slot Mating Flange | Shrouded - 4 Wall |
 Harwin Inc. | 7.3 mm 9.75 mm | 800 V | 1 | Solder | Threaded | Gold | Circular | Polyphenylene Sulfide (PPS) Glass Filled | Header | 5.6 mm | 0.22 in | 4 mm | 0.157 in | Through Hole | -55 C | 125 °C | 0.76 Ám | 30 Áin | Copper Alloy | All | UL94 V-0 | 0.138 in | 3.5 mm | 40 A | 6 | Male Pin Power | Board to Cable/Wire | Black | Keying Slot Mating Flange | Shrouded - 4 Wall |
 Harwin Inc. | 7.3 mm 9.75 mm | 800 V | 1 | Solder | Threaded | Gold | Circular | Polyphenylene Sulfide (PPS) Glass Filled | Header | 5.6 mm | 0.22 in | 4 mm | 0.157 in | Through Hole | -55 C | 125 °C | 0.25 µm | 10 µin | Copper Alloy | All | UL94 V-0 | 0.138 in | 3.5 mm | 20 A | 6 | Male Pin Power | Board to Cable/Wire | Black | Keying Slot Mating Flange | Shrouded - 4 Wall |
 Harwin Inc. | 7.3 mm 9.75 mm | 800 V | 1 | Solder | Threaded | Gold | Circular | Polyphenylene Sulfide (PPS) Glass Filled | Header | 5.6 mm | 0.22 in | 4 mm | 0.157 in | Through Hole | -55 C | 125 °C | 0.25 µm | 10 µin | Copper Alloy | All | UL94 V-0 | 0.138 in | 3.5 mm | 20 A | 5 | Male Pin Power | Board to Cable/Wire | Black | Keying Slot Mating Flange | Shrouded - 4 Wall |
 Harwin Inc. | 7.3 mm 9.75 mm | 800 V | 1 | Solder | Threaded | Gold | Circular | Polyphenylene Sulfide (PPS) Glass Filled | Header | 5.6 mm | 0.22 in | 4 mm | 0.157 in | Through Hole | -55 C | 125 °C | 0.25 µm | 10 µin | Copper Alloy | All | UL94 V-0 | 0.138 in | 3.5 mm | 20 A | 10 | Male Pin Power | Board to Cable/Wire | Black | Keying Slot Mating Flange | Shrouded - 4 Wall |
