C4064 Series

Catalog

CABLE 5COND 22AWG BLACK

Part	Conductor Strand [custom]	Conductor Strand [custom]	Wire Gauge	Cable Type	Voltage	Operating Temperature [Max]	Operating Temperature [Min]	Number of Conductors	Conductor Material	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Material	Jacket Color	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Conductor Insulation	Length	Length	Usage	Length [x]	Length [x]
Prysmian Group C4064A.41.01	30 AWG	7	22 AWG	Multi-Conductor	300 VDC	80 °C	-20 ░C	5	Copper Annealed Tinned	0.203 in	5.16 mm	Poly-Vinyl Chloride (PVC)	Black	0.813 mm	0.032 in	Poly-Vinyl Chloride (PVC)	304.8 m	1000 ft
Prysmian Group C4064A.38.10	30 AWG	7	22 AWG	Multi-Conductor	300 VDC	80 °C	-20 ░C	5	Copper Tinned	0.203 in	5.16 mm	Poly-Vinyl Chloride (PVC)	Gray	0.813 mm	0.032 in	Poly-Vinyl Chloride (PVC)	15.24 m 152.4 m	50 ft 500 ft	Communication Control
Prysmian Group C4064A.41.10	30 AWG	7	22 AWG	Multi-Conductor	300 VDC	80 °C	-20 ░C	5	Copper Tinned	0.203 in	5.16 mm	Poly-Vinyl Chloride (PVC)	Gray	0.813 mm	0.032 in	Poly-Vinyl Chloride (PVC)	15.24 m 152.4 m 304.8 m	50 ft 500 ft 1000 ft	Communication Control	100 ft	30.5 m
Prysmian Group C4064A.38.10	30 AWG	7	22 AWG	Multi-Conductor	300 VDC	80 °C	-20 ░C	5	Copper Tinned	0.203 in	5.16 mm	Poly-Vinyl Chloride (PVC)	Gray	0.813 mm	0.032 in	Poly-Vinyl Chloride (PVC)	152.4 m	500 ft	Communication Control
Prysmian Group C4064A.41.10	30 AWG	7	22 AWG	Multi-Conductor	300 VDC	80 °C	-20 ░C	5	Copper Tinned	0.203 in	5.16 mm	Poly-Vinyl Chloride (PVC)	Gray	0.813 mm	0.032 in	Poly-Vinyl Chloride (PVC)	15.24 m 304.8 m	50 ft 1000 ft	Communication Control	100 ft	30.5 m
Prysmian Group C4064A.41.01	30 AWG	7	22 AWG	Multi-Conductor	300 VDC	80 °C	-20 ░C	5	Copper Annealed Tinned	0.203 in	5.16 mm	Poly-Vinyl Chloride (PVC)	Black	0.813 mm	0.032 in	Poly-Vinyl Chloride (PVC)	304.8 m	1000 ft
