A3C-12P Series

Catalog

CONN HEADER VERT 12POS 2MM

Part	Contact Finish Thickness - Post	Mated Stacking Heights	Insulation Color	Insulation Height [z]	Insulation Height [z]	Connector Type	Material Flammability Rating	Number of Positions Loaded	Contact Type	Contact Finish - Post	Style	Number of Positions	Shrouding	Row Spacing - Mating	Row Spacing - Mating	Contact Material	Overall Contact Length	Overall Contact Length	Contact Finish - Mating	Pitch - Mating	Pitch - Mating	Contact Length - Mating	Contact Length - Mating	Number of Rows [custom]	Insulation Material	Termination	Contact Length - Post	Contact Length - Post	Contact Shape	Voltage Rating	Mounting Type	Fastening Type	Operating Temperature [Min]	Operating Temperature [Max]	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Insulation Height	Insulation Height
Hirose Electric Co Ltd A3C-12P-2DSA	Flash	5.1 mm 7.9 mm	Black	0.9 mm	0.035 in	Header	UL94 V-0	All	Male Pin	Gold	Board to Board Cable	12	Unshrouded	2 mm	0.079 in	Brass	7 mm	0.276 in	Gold	0.079 "	2 mm	3.5 mm	0.138 in	2	Nylon Polyamide (PA)	Solder	2.6 mm	0.102 in	Square	200 V	Through Hole	Push-Pull	-55 C	85 °C	8 µin	0.203 µm
Hirose Electric Co Ltd A3C-12P-2DSA(30)			Black			Header	UL94 V-0	All	Male Pin		Board to Board Cable	12	Unshrouded	2 mm	0.079 in	Brass	7 mm	0.276 in	Gold	0.079 "	2 mm	3.5 mm	0.138 in	2	Nylon Polyamide (PA)	Solder	2.6 mm	0.102 in	Square	200 VAC	Through Hole	Push-Pull	-55 C	85 °C			4.4 mm	0.173 in
