BD436 Series

PNP Bipolar Power Transistor

Catalog

PNP Bipolar Power Transistor

Part	Vce Saturation (Max) @ Ib, Ic	Current - Collector (Ic) (Max) [Max]	Frequency - Transition	Power - Max [Max]	Operating Temperature	Package / Case	Transistor Type	Voltage - Collector Emitter Breakdown (Max)	DC Current Gain (hFE) (Min) @ Ic, Vce	Supplier Device Package	Mounting Type	Current - Collector Cutoff (Max) [Max]	DC Current Gain (hFE) (Min) @ Ic, Vce [Min]	Operating Temperature [Min]	Operating Temperature [Max]
ON Semiconductor BD436G	500 mV	4 A	3 MHz	36 W	150 °C	TO-126-3 TO-225AA	PNP	32 V	50 hFE	TO-225-3	Through Hole	100 µA
ON Semiconductor BD436TG	500 mV	4 A	3 MHz	36 W		TO-126-3 TO-225AA	PNP	32 V		TO-126	Through Hole	100 µA	85	-55 °C	150 °C

PNP Bipolar Power Transistor

• Pb-Free Packages are Available

This series of plastic, medium-power PNP transistors can be used for amplifier and switching applications. Complementary types are BD437 and BD441.
