LD1085 Series

Catalog

IC REG LINEAR 1.8V 3A D2PAK

Part	Voltage Dropout (Max)	Current - Quiescent (Iq)	Mounting Type	Output Configuration	Supplier Device Package	PSRR	Operating Temperature [Max]	Operating Temperature [Min]	Protection Features	Number of Regulators	Package / Case	Voltage - Output (Min/Fixed)	Current - Output	Voltage - Input (Max) [Max]	Output Type
STMicroelectronics LD1085D2T18R	1.5 V	10 mA	Surface Mount	Positive	D2PAK	72 dB	125 °C	-40 C	Over Current Over Temperature	1	D2PAK (2 Leads + Tab) TO-263-3 TO-263AB	1.8 V	3 A	30 V
STMicroelectronics LD1085D2M18R	1.5 V	10 mA	Surface Mount	Positive	D2PAK-3	72 dB	125 °C	-40 C	Over Current Over Temperature	1	D2PAK (3 Leads + Tab) TO-263-4 TO-263AA	1.8 V	3 A	30 V
STMicroelectronics LD1085V	1.5 V	10 mA	Through Hole	Positive	TO-220	72 dB	125 °C	-40 C	Over Current Over Temperature	1	TO-220-3	1.25 V	3 A	30 V	Adjustable
STMicroelectronics LD1085D2T33R	1.5 V	10 mA	Surface Mount	Positive	D2PAK	72 dB	125 °C	-40 C	Over Current Over Temperature	1	D2PAK (2 Leads + Tab) TO-263-3 TO-263AB	3.3 V	3 A	30 V
STMicroelectronics LD1085P	1.5 V	10 mA	Through Hole	Positive	TO-220FP	72 dB	125 °C	-40 C	Over Current Over Temperature	1	TO-220-3 Full Pack	1.25 V	3 A	30 V	Adjustable
STMicroelectronics LD1085D2M-R	1.5 V	10 mA	Surface Mount	Positive	D2PAK-3	72 dB	125 °C	-40 C	Over Current Over Temperature	1	D2PAK (3 Leads + Tab) TO-263-4 TO-263AA	1.25 V	3 A	30 V	Adjustable
STMicroelectronics LD1085V18	1.5 V	10 mA	Through Hole	Positive	TO-220	72 dB	125 °C	-40 C	Over Current Over Temperature	1	TO-220-3	1.8 V	3 A	30 V
STMicroelectronics LD1085D2T12R	1.5 V	10 mA	Surface Mount	Positive	D2PAK	66 dB	125 °C	-40 C	Over Current Over Temperature	1	D2PAK (2 Leads + Tab) TO-263-3 TO-263AB	12 V	3 A	30 V
STMicroelectronics LD1085D2M50	1.5 V	10 mA	Surface Mount	Positive	D2PAK-3	72 dB	125 °C	-40 C	Over Current Over Temperature	1	D2PAK (3 Leads + Tab) TO-263-4 TO-263AA	5 V	3 A	30 V
STMicroelectronics LD1085V50	1.5 V	10 mA	Through Hole	Positive	TO-220	72 dB	125 °C	-40 C	Over Current Over Temperature	1	TO-220-3	5 V	3 A	30 V
