STPS30L60C Series

60 V, 30 A dual Low Drop Power Schottky Rectifier

Catalog

60 V, 30 A dual Low Drop Power Schottky Rectifier

Part	Diode Configuration	Supplier Device Package	Technology	Voltage - Forward (Vf) (Max) @ If	Operating Temperature - Junction [Max]	Current - Reverse Leakage @ Vr	Mounting Type	Package / Case	Current - Average Rectified (Io) (per Diode)	Voltage - DC Reverse (Vr) (Max) [Max]	Speed
STMicroelectronics STPS30L60CG-TR	1 Pair Common Cathode	D2PAK	Schottky	600 mV	150 °C	480 µA	Surface Mount	D2PAK (2 Leads + Tab) TO-263-3 TO-263AB	15 A	60 V	200 mA 500 ns
STMicroelectronics STPS30L60CW	1 Pair Common Cathode	TO-247-3	Schottky	600 mV	150 °C	480 µA	Through Hole	TO-247-3	15 A	60 V	200 mA 500 ns

Catalog

60 V, 30 A dual Low Drop Power Schottky Rectifier

Description

These dual center tap Schottky rectifiers are suited for switched mode power supplies and high frequency DC to DC converters. Packaged in TO-220FPAB, TO-220AB narrow leads, TO-220AB, D2PAK, I2PAK and TO-247, this device is intended for use in high frequency inverters.
