DF12 (3.5) Series

Catalog

CONN HDR 20POS SMD GOLD

Part	Contact Finish	Mounting Type	Height Above Board [z]	Height Above Board [z]	Pitch	Pitch	Number of Positions	Features	Number of Rows [custom]	Mated Stacking Heights	Contact Finish Thickness	Contact Finish Thickness	Connector Type
Hirose Electric Co Ltd DF12(3.5)-20DP-0.5V(86)	Gold	Surface Mount	2.8 mm	0.11 in	0.02 "	0.5 mm	20	Board Guide Solder Retention	2	3.5 mm	0.203 çm	8 µin	Header Outer Shroud Contacts
Hirose Electric Co Ltd DF12(3.5)-40DP-0.5V(86)	Gold	Surface Mount	2.8 mm	0.11 in	0.02 "	0.5 mm	40	Board Guide Solder Retention	2	3.5 mm	0.203 çm	8 µin	Header Outer Shroud Contacts
Hirose Electric Co Ltd DF12(3.5)-30DP-0.5V(86)	Gold	Surface Mount	2.8 mm	0.11 in	0.02 "	0.5 mm	30	Board Guide Solder Retention	2	3.5 mm	0.203 çm	8 µin	Header Outer Shroud Contacts
Hirose Electric Co Ltd DF12(3.5)-36DP-0.5V(86)	Gold	Surface Mount	2.8 mm	0.11 in	0.02 "	0.5 mm	36	Board Guide Solder Retention	2	3.5 mm	0.203 çm	8 µin	Header Outer Shroud Contacts
Hirose Electric Co Ltd DF12(3.5)40DP0.5V(80	Gold	Surface Mount	2.8 mm	0.11 in	0.02 "	0.5 mm	40	Board Guide Solder Retention	2	3.5 mm			Header Outer Shroud Contacts
Hirose Electric Co Ltd DF12(3.5)36DP0.5V(80	Gold	Surface Mount	2.8 mm	0.11 in	0.02 "	0.5 mm	36	Board Guide Solder Retention	2	3.5 mm			Header Outer Shroud Contacts
