A1-40PA Series

Catalog

CONN HEADER VERT 40POS 2.54MM

Part	Contact Finish Thickness - Post [custom]	Contact Finish Thickness - Post [custom]	Style	Number of Positions Loaded	Pitch - Mating	Pitch - Mating	Material Flammability Rating	Contact Length - Post	Contact Length - Post	Contact Type	Shrouding	Number of Positions	Fastening Type	Contact Length - Mating	Contact Length - Mating	Connector Type	Overall Contact Length	Overall Contact Length	Number of Rows [custom]	Contact Material	Current Rating (Amps)	Insulation Material	Insulation Color	Row Spacing - Mating [x]	Row Spacing - Mating [x]	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Termination	Operating Temperature [Min]	Operating Temperature [Max]	Mounting Type	Contact Finish - Post	Insulation Height	Insulation Height	Contact Finish - Mating	Voltage Rating	Contact Shape
Hirose Electric Co Ltd A1-40PA-2.54DSA(71)	78.7 µin	2 µm	Board to Board Cable	All	0.1 "	2.54 mm	UL94 V-0	0.118 in	3 mm	Male Pin	Unshrouded	40	Push-Pull	6 mm	0.236 in	Header	11.54 mm	0.454 "	2	Brass	3 A	Polybutylene Terephthalate (PBT)	Black	0.1 in	2.54 mm	8 µin	0.203 µm	Solder	-55 C	85 °C	Through Hole	Tin	0.1 in	2.54 mm	Gold	200 V	Square
