STM32WL33CC Series

Catalog

SUB-GHZ WIRELESS MICROCONTROLLERS. SINGLE-CORE ARM CORTEX-M0+ @64 MHZ WITH 256 KBYTES OF FLASH MEMORY, 32 KBYTES OF SRAM.

Part	Modulation	Package / Case	Memory Size	Mounting Type	Type	Power - Output	Data Rate (Max) [Max]	Serial Interfaces	Voltage - Supply [Min]	Voltage - Supply [Max]	Frequency [Max]	Frequency [Min]	RF Family/Standard	Current - Transmitting [Max]	Current - Transmitting [Min]	Sensitivity	Protocol	Operating Temperature [Min]	Operating Temperature [Max]	Supplier Device Package	GPIO	Current - Receiving
STMicroelectronics STM32WL33CCV7ATR	2-FSK 2-GFSK 4-FSK 4-GFSK ASK DBPSK DSSS FSK GFSK OOK	48-VFQFN Exposed Pad	Flash RAM	Surface Mount	TxRx + MCU	20 dBm	1.05 Mbps	GPIO I2C I2S IrDA JTAG PCM PWM SPI UART USART	1.7 V	3.6 V	185 MHz	159 MHz	802.15.4 General ISM < 1GHz	80 mA	10 mA	-132 dBm	KNX LPWAN Sigfox Zigbee®	-40 °C	105 °C	48-VFQFPN (6x6)	32	4 mA
STMicroelectronics STM32WL33CCV6A	2-FSK 2-GFSK 4-FSK 4-GFSK ASK DBPSK DSSS FSK GFSK OOK	48-VFQFN Exposed Pad	Flash RAM	Surface Mount	TxRx + MCU	20 dBm	1.05 Mbps	GPIO I2C I2S IrDA JTAG PCM PWM SPI UART USART	1.7 V	3.6 V	185 MHz	159 MHz	802.15.4 General ISM < 1GHz	80 mA	10 mA	-132 dBm	KNX LPWAN Sigfox Zigbee®	-40 ¯C	85 C	48-VFQFPN (6x6)	32	4 mA
STMicroelectronics STM32WL33CCV6	2-FSK 2-GFSK 4-FSK 4-GFSK ASK DBPSK DSSS FSK GFSK OOK	48-VFQFN Exposed Pad	Flash RAM	Surface Mount	TxRx + MCU	20 dBm	600 kbps	GPIO I2C I2S IrDA JTAG PCM PWM SPI UART USART	1.7 V	3.6 V	479 MHz 958 MHz	413 MHz 826 MHz	802.15.4 General ISM < 1GHz	80 mA	10 mA	-132 dBm	KNX LPWAN Sigfox Zigbee®	-40 ¯C	85 C	48-VFQFPN (6x6)	32	4 mA
STMicroelectronics STM32WL33CCV6ATR	2-FSK 2-GFSK 4-FSK 4-GFSK ASK DBPSK DSSS FSK GFSK OOK	48-VFQFN Exposed Pad	Flash RAM	Surface Mount	TxRx + MCU	20 dBm	1.05 Mbps	GPIO I2C I2S IrDA JTAG PCM PWM SPI UART USART	1.7 V	3.6 V	185 MHz	159 MHz	802.15.4 General ISM < 1GHz	80 mA	10 mA	-132 dBm	KNX LPWAN Sigfox Zigbee®	-40 ¯C	85 C	48-VFQFPN (6x6)	32	4 mA
STMicroelectronics STM32WL33CCV6TR	2-FSK 2-GFSK 4-FSK 4-GFSK ASK DBPSK DSSS OOK	48-VFQFN Exposed Pad	Flash RAM	Surface Mount	TxRx + MCU	20 dBm	600 kbps	GPIO I2C I2S IrDA JTAG PCM PWM SPI UART USART	1.7 V	3.6 V	479 MHz 958 MHz	413 MHz 826 MHz	802.15.4	80 mA	10 mA	-132 dBm	KNX LPWAN Sigfox Zigbee®	-40 ¯C	85 C	48-VFQFPN (6x6)	32	4 mA
STMicroelectronics STM32WL33CCV7A	2-FSK 2-GFSK 4-FSK 4-GFSK ASK DBPSK DSSS FSK GFSK OOK	48-VFQFN Exposed Pad	Flash RAM	Surface Mount	TxRx + MCU	20 dBm	1.05 Mbps	GPIO I2C I2S IrDA JTAG PCM PWM SPI UART USART	1.7 V	3.6 V	185 MHz	159 MHz	802.15.4 General ISM < 1GHz	80 mA	10 mA	-132 dBm	KNX LPWAN Sigfox Zigbee®	-40 °C	105 °C	48-VFQFPN (6x6)	32	4 mA
STMicroelectronics STM32WL33CCV7TR	2-FSK 2-GFSK 4-FSK 4-GFSK ASK DBPSK DSSS OOK	48-VFQFN Exposed Pad	Flash RAM	Surface Mount	TxRx + MCU	20 dBm	600 kbps	GPIO I2C I2S IrDA JTAG PCM PWM SPI UART USART	1.7 V	3.6 V	479 MHz 958 MHz	413 MHz 826 MHz	802.15.4	80 mA	10 mA	-132 dBm	KNX LPWAN Sigfox Zigbee®	-40 °C	105 °C	48-VFQFPN (6x6)	32	4 mA
STMicroelectronics STM32WL33CCV7	2-FSK 2-GFSK 4-FSK 4-GFSK ASK DBPSK DSSS FSK GFSK OOK	48-VFQFN Exposed Pad	Flash RAM	Surface Mount	TxRx + MCU	20 dBm	600 kbps	GPIO I2C I2S IrDA JTAG PCM PWM SPI UART USART	1.7 V	3.6 V	479 MHz 958 MHz	413 MHz 826 MHz	802.15.4 General ISM < 1GHz	80 mA	10 mA	-132 dBm	KNX LPWAN Sigfox Zigbee®	-40 °C	105 °C	48-VFQFPN (6x6)	32	4 mA
