Pch -30V -18A Middle Power MOSFET
Description
AI
RQ3E075AT is high power small mold package(HSMT8) MOSFET for switching application.
Beta
⌘K
Pch -30V -18A Middle Power MOSFET
Pch -30V -18A Middle Power MOSFET
| Part | Drain to Source Voltage (Vdss) | Drive Voltage (Max Rds On, Min Rds On) | Gate Charge (Qg) (Max) @ Vgs | Rds On (Max) @ Id, Vgs [Max] | Input Capacitance (Ciss) (Max) @ Vds | Vgs (Max) | Current - Continuous Drain (Id) @ 25°C | Operating Temperature [Max] | Operating Temperature [Min] | FET Type | Mounting Type | Vgs(th) (Max) @ Id | Power Dissipation (Max) | Technology | Supplier Device Package [x] | Supplier Device Package [custom] | Supplier Device Package [y] | Package / Case |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Rohm Semiconductor | 30 V | 10 V | 10.4 nC | 23 mOhm | 930 pF | 20 V | 18 A | 150 °C | -55 °C | P-Channel | Surface Mount | 2.5 V | 15 W | MOSFET (Metal Oxide) | 3.2 | 8-HSMT | 3 | 8-PowerVDFN |
