PCS15-D Series

Catalog

SSR RELAY 40A 48~440VAC SCREW TE

Part	Package Name	Termination Style	Operating Temperature (Min)	Operating Temperature (Max)	Voltage - Load (Min)	Voltage - Load (Max)	Package / Case	Load Current	Voltage - Input (DC) Maximum	Voltage - Input (DC) Minimum	Approval Agency	Mounting Type	Output Type	Circuit	Quick Connect Size (0.250")
Picker Components PCS15-D-380A-40ZL	Hockey Puck	Screw Terminal	-30 °C	80 °C	48 V	440 V	Hockey Puck	40 A	32 VDC	4 VDC	cURus	Chassis Mount	AC Zero Cross	SPST-NO (1 Form A)
Picker Components PCS15-D-240A-40RYLQ	Hockey Puck	Quick Connect	-30 °C	80 °C	48 V	280 V	Hockey Puck	40 A	32 VDC	4 VDC	cURus	Chassis Mount	AC	SPST-NO (1 Form A)	0.25 in
Picker Components PCS15-D-240A-10RL	Hockey Puck	Screw Terminal	-30 °C	80 °C	48 V	280 V	Hockey Puck	10 A	32 VDC	4 VDC	cURus	Chassis Mount	AC	SPST-NO (1 Form A)
Picker Components PCS15-D-380A-10ZL	Hockey Puck	Screw Terminal	-30 °C	80 °C	48 V	440 V	Hockey Puck	10 A	32 VDC	4 VDC	cURus	Chassis Mount	AC Zero Cross	SPST-NO (1 Form A)
Picker Components PCS15-D-380A-40RL	Hockey Puck	Screw Terminal	-30 °C	80 °C	48 V	440 V	Hockey Puck	40 A	32 VDC	4 VDC	cURus	Chassis Mount	AC	SPST-NO (1 Form A)
Picker Components PCS15-D-240A-25ZLQ	Hockey Puck	Quick Connect	-30 °C	80 °C	48 V	280 V	Hockey Puck	25 A	32 VDC	4 VDC	cURus	Chassis Mount	AC Zero Cross	SPST-NO (1 Form A)	0.25 in
Picker Components PCS15-D-380A-10ZYL	Hockey Puck	Screw Terminal	-30 °C	80 °C	48 V	440 V	Hockey Puck	10 A	32 VDC	4 VDC	cURus	Chassis Mount	AC Zero Cross	SPST-NO (1 Form A)
Picker Components PCS15-D-240A-40RL	Hockey Puck	Screw Terminal	-30 °C	80 °C	48 V	280 V	Hockey Puck	40 A	32 VDC	4 VDC	cURus	Chassis Mount	AC	SPST-NO (1 Form A)
Picker Components PCS15-D-380A-40ZLQ	Hockey Puck	Quick Connect	-30 °C	80 °C	48 V	440 V	Hockey Puck	40 A	32 VDC	4 VDC	cURus	Chassis Mount	AC Zero Cross	SPST-NO (1 Form A)	0.25 in
Picker Components PCS15-D-240A-25ZYLQ	Hockey Puck	Quick Connect	-30 °C	80 °C	48 V	280 V	Hockey Puck	25 A	32 VDC	4 VDC	cURus	Chassis Mount	AC Zero Cross	SPST-NO (1 Form A)	0.25 in
