Ultra-low power, Touch and Smart Analog
Key Features
• Processor:* Arm® Cortex®-M23
• * 48 MHz (2.64 CoreMark/MHz)
• * Hardware divider
• * Nested Vector Interrupt Controller (NVIC)
• * Memory Protection Unit (MPU)
•
• Operating Voltage Range:* 1.62V to 3.63V
•
• Memory:* 512 KB Flash
• * 64 KB SRAM
• * 16 KB Data Flash Write While Read(WWR) section
• * 512 bytes TrustRAM
•
• Ultra-Low Power:* Active, Idle, Standby with partial or full SRAM retention and off sleep modes
• * Static and dynamic power gating
• * SleepWalking peripherals
• * Event System
• * Embedded Buck/LDO regulator with on-the-fly selection
•
• Enhanced Peripheral Touch Controller (PTC):* Driven Shield Plus for moisture tolerance and noise immunity
• * Parallel Acquisition through Polarity control
• * Supports wake-up on touch from Standby Sleep mode
• * Low-power, high-sensitivity, environmentally robust capacitive touch buttons, sliders, wheels, and trackpads
•
• Advanced Analog:* 12-bit, 1 MSPS Analog-to-Digital Converter (ADC)
• * 12-bit, 1MSPS Digital-to-Analog Converter (DAC)
• * Analog Comparators (AC) with window compare function
• * Operational Amplifiers
•
• Additional Peripherals:* USB Full Speed Device and Host
• * I2S with up to 8-slot TDM and PDM microphone support
• * USART, I2C, LIN, SPI, ISO7816, RS-485
• * 16-bit & 24-bit Timer Counter for Control (TCC)
• * 16-bit Timer Counters (TC), WDT and 32-bit RTC
•
• Development Support:* MPLAB X IDE
• * MPLAB Harmony v3 & MCC
• * Two-pin Serial Wire Debug (SWD) programming and debugging interface
Description
AI
PIC32CM LE00 family of devices based on Arm® Cortex®-M23 processor bring ultra-low power, superior touch, and smart analog integration in one chip. They feature innovative low power techniques including SleepWalking peripherals, industry leading water tolerant touch, Op Amps, Analog to Digital Converter (ADC) & Digital to Analog Converter (DAC). They are supported by MPLABX IDE, MPLAB Harmony v3 and MPLAB Code Configurator (MCC).
