RED20 Series
Manufacturer: P-DUKE Technology
Beta
⌘K
DC DC CONVERTER 5V 20W
| Part | Number of Outputs | Approval Agency | Voltage - Input (Max) | Applications | Size / Dimension Width | Size / Dimension Length | Size / Dimension Height | Voltage - Output 1 | Features | Voltage - Isolation | Type | Efficiency | Operating Temperature (Min) | Operating Temperature (Max) | Control Features | Current - Output (Max) | Mounting Type | Package / Case | Voltage - Input (Min) | Power (Watts) | Standard Number |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 P-DUKE Technology | 1 | CB CE cURus | 36 V | ITE (Commercial) | 1 in | 2 in | 0.4 in | 5 V | Adjustable Output Remote On/Off Standby Output | 2.25 kV | Isolated Module | 88 % | -40 °C | 101 °C | Active Low Enable | 4 A | Through Hole | 6-DIP Module | 9 V | 20 W | 60950-1 |
P-DUKE Technology | 1 | CB CE cURus | 75 V | ITE (Commercial) | 1 in | 2 in | 0.4 in | 12 V | Adjustable Output Remote On/Off Standby Output | 2.25 kV | Isolated Module | 89 % | -40 °C | 101 °C | Active Low Enable | 1.67 A | Through Hole | 6-DIP Module | 18 V | 20 W | 60950-1 |
