A2-19PA Series

Catalog

CONN HEADER VERT 19POS 2.54MM

Part	Contact Finish Thickness - Post [custom]	Contact Finish Thickness - Post [custom]	Number of Rows	Style	Insulation Color	Contact Length - Mating	Contact Length - Mating	Insulation Height	Insulation Height	Overall Contact Length	Overall Contact Length	Current Rating (Amps)	Contact Finish - Post	Material Flammability Rating	Pitch - Mating	Pitch - Mating	Contact Shape	Fastening Type	Contact Material	Voltage Rating	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Insulation Material	Contact Finish - Mating	Contact Length - Post	Contact Length - Post	Connector Type	Operating Temperature [Min]	Operating Temperature [Max]	Number of Positions	Shrouding	Mounting Type	Contact Type	Number of Positions Loaded	Termination	Insulation Height [z]	Insulation Height [z]
Hirose Electric Co Ltd A2-19PA-2.54DSA(71)	78.7 µin	2 µm	1	Board to Board Cable	Black	6 mm	0.236 in	0.1 in	2.54 mm	11.54 mm	0.454 "	3 A	Tin	UL94 V-0	0.1 "	2.54 mm	Square	Push-Pull	Brass	200 V	8 µin	0.203 µm	Polybutylene Terephthalate (PBT)	Gold	0.118 in	3 mm	Header	-55 C	85 °C	19	Unshrouded	Through Hole	Male Pin	All	Solder
Hirose Electric Co Ltd A2-19PA-2.54DS(71)	78.7 µin	2 µm	1	Board to Board Cable	Black	6 mm	0.236 in					3 A	Tin	UL94 V-0	0.1 "	2.54 mm	Square	Push-Pull	Brass	200 V	8 µin	0.203 µm	Polybutylene Terephthalate (PBT)	Gold	0.138 in	3.5 mm	Header	-55 C	85 °C	19	Unshrouded	Right Angle Through Hole	Male Pin	All	Solder	4 mm	0.157 in
