UCL Series

Manufacturer: Nichicon

Catalog

SMD ALUMINUM ELECTROLYTIC CAPACITOR, RADIAL CAN - SMD, 10 ΜF, 16 V, 2000 HOURS @ 85°C, POLAR

Part	Operating Temperature [Min]	Operating Temperature [Max]	Ratings	Mounting Type	Size / Dimension [diameter]	Size / Dimension [diameter]	Surface Mount Land Size [x]	Surface Mount Land Size [y]	Surface Mount Land Size [x]	Surface Mount Land Size [y]	Applications	Package / Case	Ripple Current @ High Frequency	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Tolerance	Lifetime @ Temp.	Polarization	Ripple Current @ Low Frequency	Capacitance	Impedance	Voltage - Rated	Height - Seated (Max)	Height - Seated (Max) [Max]
Nichicon UCL1C100MCL1GS	-55 C	105 ░C	AEC-Q200	Surface Mount	4 mm	0.157 in	4.3 mm	0.169 "	0.169 in	4.3 mm	General Purpose	Radial Can - SMD	160 mA	0.228 "	5.8 mm	20 %	2000 Hrs	Polar	80 mA	10 µF	850 mOhm	16 V
Nichicon UCL1V151MCL6GS	-55 C	105 ░C	AEC-Q200	Surface Mount	10 mm	0.394 in	10.3 mm	0.406 in	0.406 "	10.3 mm	General Purpose	Radial Can - SMD	850 mA	0.303 in		20 %	2000 Hrs	Polar	425 mA	150 µF	100 mOhms	35 V	7.7 mm
Nichicon UCL1E680MCLAHFGS
Nichicon UCL1E330MCL6GS	-55 C	105 ░C	AEC-Q200	Surface Mount	5 mm	0.197 in	0.209 in 5.3 mm			0.209 in 5.3 mm	General Purpose	Radial Can - SMD	240 mA	0.228 "	5.8 mm	20 %	2000 Hrs	Polar	120 mA	33 ÁF	360 mOhms	25 VDC
Nichicon UCL1E151MCL6GS	-55 C	105 ░C	AEC-Q200	Surface Mount	10 mm	0.394 in	10.3 mm	0.406 in	0.406 "	10.3 mm	General Purpose	Radial Can - SMD	850 mA	0.303 in		20 %	2000 Hrs	Polar	425 mA	150 µF	100 mOhms	25 VDC	7.7 mm
Nichicon UCL1C470MCL6GS	-55 C	105 ░C	AEC-Q200	Surface Mount	5 mm	0.197 in	0.209 in 5.3 mm			0.209 in 5.3 mm	General Purpose	Radial Can - SMD	240 mA	0.228 "	5.8 mm	20 %	2000 Hrs	Polar	120 mA	47 µF	360 mOhms	16 V
Nichicon UCL1C471MNL1GS	-55 C	105 ░C	AEC-Q200	Surface Mount	8 mm	0.315 in	8.3 mm	0.327 in	0.327 in	8.3 mm	General Purpose	Radial Can - SMD	850 mA	0.394 in	10 mm	20 %	2000 Hrs	Polar	425 mA	470 µF	80 mOhms	16 V
Nichicon UCL1C221MCL6GS	-55 C	105 ░C	AEC-Q200	Surface Mount	8 mm	0.315 in	8.3 mm	0.327 in	0.327 in	8.3 mm	General Purpose	Radial Can - SMD	500 mA		0.256 in	20 %	2000 Hrs	Polar	250 mA	220 µF	180 mOhms	16 V		6.5 mm
