1010564 Series
Manufacturer: Integrated Power Designs
Beta
⌘K
REL-185-4005 CHCO
| Part | Current - Output 4 | Voltage - Output 2 | Voltage - Output 4 | Current - Output 2 | Mounting Type | Voltage - Output 3 | Standard Number | Current - Output 3 | Applications | Approval Agency | Current - Output 1 | Voltage - Output 1 | Power (Watts) | Operating Temperature [Max] | Operating Temperature [Min] | Type | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [y] | Features | Number of Outputs |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Integrated Power Designs | 2 A | -5 V | -15 V | 10 A | Chassis Mount | 15 V | 60601-1; 62368-1 | 2 A | Industrial ITE (Commercial) Laboratory Medical | CE cURus TUV UKCA | 20 A | 5 V | 185 W | 70 °C | 0 °C | Enclosed | 100.5 mm | 156.8 mm | 1.48 " | 6.25 " | 37.6 mm | 3.96 in | Adjustable Output Remote Sense Universal Input | 4 |
