E2032S Series

Catalog

CABLE 2COND 18AWG BLUE SHLD

Part	Wire Gauge	Features	Conductor Material	Cable Type	Number of Conductors	Shield Type	Usage	Conductor Insulation	Length [x]	Length [x]	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Thickness [x]	Jacket (Insulation) Thickness [x]	Jacket Color	Voltage	Jacket (Insulation) Material	Conductor Strand [custom]	Conductor Strand [custom]	Shield Material	Shield Coverage	Length	Length
Prysmian Group E2032S.43.07	18 AWG	Drain Wire Rip Cord	Copper Bare	Multi-Conductor	2	Foil	Alarm Security Sound	Poly-Vinyl Chloride (PVC)	2000 ft	609.6 m	4.04 mm	0.159 in	0.381 mm	0.015 in	Blue	300 VDC	Poly-Vinyl Chloride (PVC)	26 AWG	7
Prysmian Group E2032S.43.03	18 AWG	Drain Wire Rip Cord	Copper Bare	Multi-Conductor	2	Foil		Poly-Vinyl Chloride (PVC)	2000 ft	609.6 m	4.04 mm	0.159 in	0.381 mm	0.015 in	Red	300 VDC	Poly-Vinyl Chloride (PVC) Riser	26 AWG	7	Flexfoil®	100 %
Prysmian Group E2032S.43.19	18 AWG	Drain Wire Rip Cord	Copper Bare	Multi-Conductor	2	Foil	Alarm Security Sound	Poly-Vinyl Chloride (PVC)	2000 ft	609.6 m	4.04 mm	0.159 in	0.381 mm	0.015 in	Purple	300 VDC	Poly-Vinyl Chloride (PVC)	26 AWG	7
Prysmian Group E2032S.41.10	18 AWG	Drain Wire Rip Cord	Copper Bare	Multi-Conductor	2	Foil	Alarm Security Sound	Poly-Vinyl Chloride (PVC)	100 ft	30.5 m	4.04 mm	0.159 in	0.381 mm	0.015 in	Gray	300 VDC	Poly-Vinyl Chloride (PVC)	26 AWG	7			15.24 m 152.4 m 304.8 m	50 ft 500 ft 1000 ft
Prysmian Group E2032S.18.10	18 AWG	Drain Wire Rip Cord	Copper Bare	Multi-Conductor	2	Foil	Alarm Security Sound	Poly-Vinyl Chloride (PVC)			4.04 mm	0.159 in	0.381 mm	0.015 in	Gray	300 VDC	Poly-Vinyl Chloride (PVC)	26 AWG	7	Flexfoil®	100 %	15.24 m 152.4 m	50 ft 500 ft
Prysmian Group E2032S.25.10	18 AWG	Drain Wire Rip Cord	Copper Bare	Multi-Conductor	2	Foil	Alarm Security Sound	Poly-Vinyl Chloride (PVC)			4.04 mm	0.159 in	0.381 mm	0.015 in	Gray	300 VDC	Poly-Vinyl Chloride (PVC)	26 AWG	7	Flexfoil®	100 %	152.4 m	500 ft
Prysmian Group E2032S.41.10	18 AWG	Drain Wire Rip Cord	Copper Bare	Multi-Conductor	2	Foil	Alarm Security Sound	Poly-Vinyl Chloride (PVC)			4.04 mm	0.159 in	0.381 mm	0.015 in	Gray	300 VDC	Poly-Vinyl Chloride (PVC)	26 AWG	7	Flexfoil®	100 %	15.24 m 152.4 m 304.8 m	50 ft 500 ft 1000 ft
Prysmian Group E2032S.43.03	18 AWG	Drain Wire Rip Cord	Copper Bare	Multi-Conductor	2	Foil		Poly-Vinyl Chloride (PVC)	2000 ft	609.6 m	4.04 mm	0.159 in	0.381 mm	0.015 in	Red	300 VDC	Poly-Vinyl Chloride (PVC) Riser	26 AWG	7
Prysmian Group E2032S.41.03	18 AWG	Drain Wire Rip Cord	Copper Bare	Multi-Conductor	2	Foil	Alarm Security Sound	Poly-Vinyl Chloride (PVC)			4.04 mm	0.159 in	0.381 mm	0.015 in	Red	300 VDC	Poly-Vinyl Chloride (PVC)	26 AWG	7	Flexfoil®	100 %	304.8 m	1000 ft
Prysmian Group E2032S.30.10	18 AWG	Drain Wire Rip Cord	Copper Bare	Multi-Conductor	2	Foil	Alarm Security Sound	Poly-Vinyl Chloride (PVC)	100 ft	30.5 m	4.04 mm	0.159 in	0.381 mm	0.015 in	Gray	300 VDC	Poly-Vinyl Chloride (PVC)	26 AWG	7	Flexfoil®	100 %	304.8 m	1000 ft
