1.50mm Pitch CLIK-Mate Wire-to-Board PCB Receptacle, Dual Row, Surface Mount, Vertical, 0.76µm Gold (Au) Plating, 32 Circuits, Natural
1.50mm Pitch CLIK-Mate Wire-to-Board PCB Receptacle, Dual Row, Surface Mount, Vertical, 0.76µm Gold (Au) Plating, 32 Circuits, Natural
1.50mm Pitch CLIK-Mate Wire-to-Board PCB Receptacle, Dual Row, Surface Mount, Vertical, 0.76µm Gold (Au) Plating, 32 Circuits, Natural
| Part | Operating Temperature [Min] | Operating Temperature [Max] | Connector Type | Contact Finish - Mating | Contact Material | Insulation Height [z] | Insulation Height [z] | Number of Rows | Termination | Insulation Material | Insulation Color | Material Flammability Rating | Mounting Type | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Number of Positions Loaded | Fastening Type | Contact Finish Thickness - Post | Contact Finish Thickness - Post | Contact Type | Contact Finish - Post | Current Rating (Amps) | Voltage Rating | Style | Features | Number of Positions | Number of Positions |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Molex | -40 °C | 105 ░C | Receptacle | Gold | Copper Alloy | 0.346 in | 8.8 mm | 2 | Solder | Nylon Polyamide (PA) | Black | UL94 V-0 | Surface Mount | 3.94 µin | 0.1 µm | All | Latch Holder | 1 çm | 39.4 çin | Forked | Tin | Varies by Wire Gauge | 100 VAC | Board to Cable/Wire | Pick and Place Solder Retention | 28 | |
 Molex | -40 °C | 105 ░C | Receptacle | Gold | Copper Alloy | 0.346 in | 8.8 mm | 2 | Solder | Nylon Polyamide (PA) | Black | UL94 V-0 | Surface Mount | 30 Áin | 0.76 Ám | All | Latch Holder | 1 çm | 39.4 çin | Forked | Tin | Varies by Wire Gauge | 100 VAC | Board to Cable/Wire | Pick and Place Solder Retention | 30 | |
 Molex | -40 °C | 105 ░C | Receptacle | Gold | Copper Alloy | 0.346 in | 8.8 mm | 2 | Solder | Nylon Polyamide (PA) | Black | UL94 V-0 | Surface Mount | 3.94 µin | 0.1 µm | All | Latch Holder | 1 çm | 39.4 çin | Forked | Tin | Varies by Wire Gauge | 100 VAC | Board to Cable/Wire | Pick and Place Solder Retention | 20 | |
 Molex | -40 °C | 105 ░C | Receptacle | Gold | Copper Alloy | 0.346 in | 8.8 mm | 2 | Solder | Nylon Polyamide (PA) | Black | UL94 V-0 | Surface Mount | 15 µin | 0.38 µm | All | Latch Holder | 1 çm | 39.4 çin | Forked | Tin | Varies by Wire Gauge | 100 VAC | Board to Cable/Wire | Pick and Place Solder Retention | 8 | |
Molex | -40 °C | 105 ░C | Receptacle | Gold | Copper Alloy | 0.346 in | 8.8 mm | 2 | Solder | Nylon Polyamide (PA) | Black | UL94 V-0 | Surface Mount | 3.94 µin | 0.1 µm | All | Latch Holder | 1 çm | 39.4 çin | Forked | Tin | Varies by Wire Gauge | 100 VAC | Board to Cable/Wire | Pick and Place Solder Retention | 34 | |
Molex | -40 °C | 105 ░C | Receptacle | Gold | Copper Alloy | 0.346 in | 8.8 mm | 2 | Solder | Nylon Polyamide (PA) | Black | UL94 V-0 | Surface Mount | 30 Áin | 0.76 Ám | All | Latch Holder | 1 çm | 39.4 çin | Forked | Tin | Varies by Wire Gauge | 100 VAC | Board to Cable/Wire | Pick and Place Solder Retention | 16 | |
 Molex | -40 °C | 105 ░C | Receptacle | Gold | Copper Alloy | 0.346 in | 8.8 mm | 2 | Solder | Nylon Polyamide (PA) | Black | UL94 V-0 | Surface Mount | 15 µin | 0.38 µm | All | Latch Holder | 1 çm | 39.4 çin | Forked | Tin | Varies by Wire Gauge | 100 VAC | Board to Cable/Wire | Pick and Place Solder Retention | 12 | |
 Molex | -40 °C | 105 ░C | Receptacle | Gold | Copper Alloy | 0.346 in | 8.8 mm | 2 | Solder | Nylon Polyamide (PA) | Natural | UL94 V-0 | Surface Mount | 30 Áin | 0.76 Ám | All | Latch Holder | 1 çm | 39.4 çin | Forked | Tin | Varies by Wire Gauge | 100 VAC | Board to Cable/Wire | Pick and Place Solder Retention | 10 | |
Molex | -40 °C | 105 ░C | Receptacle | Gold | Copper Alloy | 0.346 in | 8.8 mm | 2 | Solder | Nylon Polyamide (PA) | Black | UL94 V-0 | Surface Mount | 15 µin | 0.38 µm | All | Latch Holder | 1 çm | 39.4 çin | Forked | Tin | Varies by Wire Gauge | 100 VAC | Board to Cable/Wire | Pick and Place Solder Retention | 24 | |
 Molex | -40 °C | 105 ░C | Receptacle | Gold | Copper Alloy | 0.346 in | 8.8 mm | 2 | Solder | Nylon Polyamide (PA) | Black | UL94 V-0 | Surface Mount | 30 Áin | 0.76 Ám | All | Latch Holder | 1 çm | 39.4 çin | Forked | Tin | Varies by Wire Gauge | 100 VAC | Board to Cable/Wire | Pick and Place Solder Retention | 22 positions |
