PDTC115 Series

50 V, 20 mA NPN resistor-equipped transistor; R1 = 100 kΩ, R2 = 100 kΩ

Catalog

50 V, 20 mA NPN resistor-equipped transistor; R1 = 100 kΩ, R2 = 100 kΩ

Part	Power - Max [Max]	Voltage - Collector Emitter Breakdown (Max) [Max]	Grade	Supplier Device Package	Transistor Type	Resistor - Base (R1)	Resistor - Emitter Base (R2)	Current - Collector Cutoff (Max) [Max]	Package / Case	Qualification	Mounting Type	Current - Collector (Ic) (Max) [Max]	DC Current Gain (hFE) (Min) @ Ic, Vce [Min]	Resistors Included	Vce Saturation (Max) @ Ib, Ic
Nexperia USA Inc. PDTC115TMB,315
Nexperia USA Inc. PDTC115EU,115	200 mW	50 V	Automotive	SOT-323	NPN - Pre-Biased	100 kOhms	100 kOhms	1 µA	SC-70 SOT-323	AEC-Q100	Surface Mount	20 mA	80	R1 R2	150 mV
Nexperia USA Inc. PDTC115ET,215	250 mW	50 V	Automotive	TO-236AB	NPN - Pre-Biased	100 kOhms	100 kOhms	1 µA	SC-59 SOT-23-3 TO-236-3	AEC-Q100	Surface Mount	20 mA	80		150 mV
Nexperia USA Inc. PDTC115EMB,315
Nexperia USA Inc. PDTC115TT,215	250 mW	50 V		TO-236AB	NPN - Pre-Biased	100 kOhms		1 µA	SC-59 SOT-23-3 TO-236-3		Surface Mount	100 mA	100		150 mV
Nexperia USA Inc. PDTC115TM,315	250 mW	50 V	Automotive	SOT-883	NPN - Pre-Biased	100 kOhms		1 µA	SC-101 SOT-883	AEC-Q100	Surface Mount	100 mA	100		150 mV
Nexperia USA Inc. PDTC115TU,115	200 mW	50 V	Automotive	SOT-323	NPN - Pre-Biased	100 kOhms		1 µA	SC-70 SOT-323	AEC-Q100	Surface Mount	100 mA	100		150 mV

Catalog

50 V, 20 mA NPN resistor-equipped transistor; R1 = 100 kΩ, R2 = 100 kΩ

Description

NPN Resistor-Equipped Transistor (RET) in a leadless ultra small DFN1006B-3 (SOT883B) Surface-Mounted Device (SMD) plastic package. PNP complement: PDTA115TMB.
