857-044 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 88POS 0.156
| Part | Contact Finish | Material - Insulation | Card Thickness [Max] | Card Thickness [Min] | Termination | Gender | Number of Positions/Bay/Row | Pitch | Pitch | Number of Positions | Termination Rows | Mounting Type | Read Out | Contact Finish Thickness | Contact Finish Thickness | Card Type | Contact Type | Contact Material | Color | Number of Rows [custom] | Operating Temperature [Max] | Operating Temperature [Min] | Number of Rows | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Termination Rows [custom] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Gold | Polyphenylene Sulfide (PPS) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Female | 44 | 3.96 mm | 0.156 in | 88 | 1 | Through Hole | Dual | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Semi Bellows | Copper Alloy | Black | 2 | 125 °C | -40 C | ||||||
 EDAC Inc. | Tin | Polyphenylene Sulfide (PPS) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Female | 44 | 3.96 mm | 0.156 in | 44 | 1 | Right Angle Through Hole | Single | Non Specified - Single Edge | Semi Bellows | Copper Alloy | Black | 125 °C | -40 C | 1 | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | |||||
 EDAC Inc. | Gold | Polyphenylene Sulfide (PPS) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Female | 22 | 3.96 mm | 0.156 in | 44 | Board Edge Straddle Mount | Dual | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Semi Bellows | Copper Alloy | Black | 2 | 125 °C | -40 C | 4-40 Flush Mount Threaded Insert Top Opening | 2 | Card Extender | ||||
 EDAC Inc. | Tin | Polyphenylene Sulfide (PPS) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Female | 44 | 3.96 mm | 0.156 in | 88 | 1 | Right Angle Through Hole | Dual | Non Specified - Dual Edge | Semi Bellows | Copper Alloy | Black | 2 | 125 °C | -40 C | ||||||||
 EDAC Inc. | Gold | Polyphenylene Sulfide (PPS) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Female | 44 | 3.96 mm | 0.156 in | 88 | 1 | Right Angle Through Hole | Dual | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Semi Bellows | Copper Alloy | Black | 2 | 125 °C | -40 C | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | |||
 EDAC Inc. | Gold | Polyphenylene Sulfide (PPS) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Female | 44 | 3.96 mm | 0.156 in | 88 | 1 | Through Hole | Dual | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Semi Bellows | Copper Alloy | Black | 2 | 125 °C | -40 C | 4-40 Flush Mount Threaded Insert Top Opening | |||||
 EDAC Inc. | Gold | Polyphenylene Sulfide (PPS) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Wire Wrap | Female | 22 | 3.96 mm | 0.156 in | 44 | Through Hole | Dual | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Semi Bellows | Copper Alloy | Black | 2 | 125 °C | -40 C | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | 2 | |||
 EDAC Inc. | Gold | Polyphenylene Sulfide (PPS) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Female | 44 | 3.96 mm | 0.156 in | 88 | 1 | Right Angle Through Hole | Dual | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Semi Bellows | Copper Alloy | Black | 2 | 125 °C | -40 C | ||||||
 EDAC Inc. | Gold | Polyphenylene Sulfide (PPS) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Female | 22 | 3.96 mm | 0.156 in | 44 | Through Hole | Dual | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Semi Bellows | Copper Alloy | Black | 2 | 125 °C | -40 C | 4-40 Flush Mount Threaded Insert Top Opening | 2 | |||||
 EDAC Inc. | Gold | Polyphenylene Sulfide (PPS) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder Eyelet(s) | Female | 44 | 3.96 mm | 0.156 in | 44 | 1 | Through Hole | Single | 0.25 Ám | 10 Áin | Non Specified - Single Edge | Semi Bellows | Copper Alloy | Black | 125 °C | -40 C | 1 | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm |
