AD7574 Series

8-Bit Analog-to-Digital Converter

Catalog

8-Bit Analog-to-Digital Converter

Part	Number of A/D Converters	Package / Case	Package / Case [x]	Package / Case [x]	Number of Inputs	Reference Type	Supplier Device Package	Operating Temperature [Max]	Operating Temperature [Min]	Mounting Type	Configuration	Data Interface	Voltage - Supply, Analog	Voltage - Supply, Digital	Number of Bits	Input Type	Architecture
Analog Devices AD7574JNZ	1	18-DIP	0.3 in	7.62 mm	1	External	18-PDIP	70 °C	0 °C	Through Hole	ADC	Parallel	5 V	5 V	8	Single Ended	SAR
Analog Devices AD7574TQ/883B
Analog Devices AD7574AQ	1	24-CDIP			1	External	24-CDIP	85 °C	-25 °C	Through Hole	ADC	Parallel	5 V	5 V	8	Single Ended	SAR
Analog Devices AD7574BQ	1	24-CDIP			1	External	24-CDIP	85 °C	-25 °C	Through Hole	ADC	Parallel	5 V	5 V	8	Single Ended	SAR
Analog Devices AD7574TQ	1	24-CDIP			1	External	24-CDIP	125 °C	-55 °C	Through Hole	ADC	Parallel	5 V	5 V	8	Single Ended	SAR
Analog Devices AD7574SQ	1	24-CDIP			1	External	24-CDIP	125 °C	-55 °C	Through Hole	ADC	Parallel	5 V	5 V	8	Single Ended	SAR
Analog Devices AD7574JN	1	18-DIP	0.3 in	7.62 mm	1	External	18-PDIP	70 °C	0 °C	Through Hole	ADC	Parallel	5 V	5 V	8	Single Ended	SAR

Catalog

8-Bit Analog-to-Digital Converter

Key Features

• 8-Bit Resolution

• No Missed Codes over Full Temperature Range

• Fast Conversion Time: 15 µs

• Interfaces to µP like RAM, ROM of Slow - Memory

• Low Power Dissipation: 30 mW

• Ratiometric Capability

• Single +5V Supply

• Low Cost

• Internal Comparator and Clock Oscillator

Description

The AD7574 is an 8-bit microprocessor compatible A/D converter with a parallel interface, 15 µs conversion time, ratiometric capability and runs from a single 5 V supply.
