LGC Series
Manufacturer: Nichicon
Beta
⌘K
ALUMINUM ELECTROLYTIC CAPACITORS - SNAP IN 500VDC 220UF 20% 35 X 25MM BL SNAP-IN BLOCK TYPE
| Part | Size / Dimension [diameter] | Size / Dimension [diameter] | Capacitance | Polarization | Ripple Current @ Low Frequency | Lifetime @ Temp. | Applications | Package / Case | Tolerance | Lead Spacing | Lead Spacing | Voltage - Rated | Height - Seated (Max) [Max] [z] | Height - Seated (Max) [Max] [z] | Ripple Current @ High Frequency | Mounting Type | Operating Temperature [Min] | Operating Temperature [Max] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Nichicon | 1.378 " | 35 mm | 220 µF | Polar | 1.2 A | 5000 Hrs | General Purpose | Radial Can - Snap-In | 20 % | 0.394 in | 10 mm | 500 V | 1.083 in | 27.5 mm | 1.716 A | Through Hole | -40 C | 105 ░C |
Nichicon | 1.378 " | 35 mm | 330 µF | Polar | 1.63 A | 5000 Hrs | General Purpose | Radial Can - Snap-In | 20 % | 0.394 in | 10 mm | 500 V | 1.476 in | 37.5 mm | 2.3309 A | Through Hole | -40 C | 105 ░C |
