MSD30US05 Series
Manufacturer: P-DUKE Technology
Beta
⌘K
AC/DC CONVERTER 5V 30W
| Part | Line Regulation | Load Regulation | Approval Agency | Features | Type | Voltage - Output 1 | Package / Case | Size / Dimension [y] | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [x] | Size / Dimension [z] | Voltage - Input [Min] | Voltage - Input [Max] | Efficiency | Number of Outputs | Applications | Operating Temperature [Min] | Operating Temperature [Max] | Mounting Type | Power (Watts) | Current - Output (Max) [Max] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 P-DUKE Technology | 2 % | 0.7 % | CB CE cURus FCC | Adjustable Output Universal Input | Enclosed | 5 V | 5-DIP Module | 1.5 " | 38.1 mm | 25.4 mm | 73.3 mm | 2.89 in | 1 in | 85 VAC 120 VDC | 264 VAC 370 VDC | 87 % | 1 | ITE (Commercial) Medical | -40 °C | 85 °C | Through Hole | 30 Watts | 6 A |
