HNC2 Series
Headers & Wire Housings 2.5MM CONT PITCH PIN HDR 15 CONT RA
Manufacturer: Hirose Electric Co Ltd
Catalog
Headers & Wire Housings 2.5MM CONT PITCH PIN HDR 15 CONT RA
Beta
⌘K
Headers & Wire Housings 2.5MM CONT PITCH PIN HDR 15 CONT RA
Headers & Wire Housings 2.5MM CONT PITCH PIN HDR 15 CONT RA
Headers & Wire Housings 2.5MM CONT PITCH PIN HDR 15 CONT RA
| Part | Mated Stacking Heights | Insulation Color | Mounting Type | Contact Type | Voltage Rating | Termination | Connector Type | Operating Temperature [Min] | Operating Temperature [Max] | Material Flammability Rating | Number of Positions Loaded | Number of Rows | Contact Length - Post | Contact Length - Post | Contact Material | Fastening Type | Pitch - Mating | Pitch - Mating | Contact Shape | Style | Contact Length - Mating | Contact Length - Mating | Shrouding | Insulation Height | Insulation Height | Overall Contact Length | Overall Contact Length | Number of Positions | Insulation Material | Contact Finish Thickness - Mating [custom] | Contact Finish Thickness - Mating [custom] | Contact Finish - Post | Contact Finish - Mating | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Note |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Hirose Electric Co Ltd | 15.5 mm | Black | Through Hole | Male Pin | 250 V | Solder | Header | -55 C | 85 °C | UL94 V-0 | All | 1 | 0.118 in | 3 mm | Brass | Push-Pull | 2.5 mm | 0.098 in | Square | Board to Board Cable | 0.197 in | 5 mm | Unshrouded | 0.256 in | 6.5 mm | 0.433 in | 11 mm | 2 | Nylon Polyamide (PA) | |||||||
Hirose Electric Co Ltd | 15.5 mm | Black | Through Hole | Male Pin | 250 V | Solder | Header | -55 C | 85 °C | UL94 V-0 | All | 1 | 0.118 in | 3 mm | Brass | Push-Pull | 2.5 mm | 0.098 in | Square | Board to Board Cable | 0.197 in | 5 mm | Unshrouded | 0.256 in | 6.5 mm | 0.433 in | 11 mm | 6 | Nylon Polyamide (PA) | 39.4 µin | 1 µm | |||||
Hirose Electric Co Ltd | Black | Right Angle Through Hole | Male Pin | 250 V | Solder | Header | -55 C | 85 °C | UL94 V-0 | All | 1 | 0.118 in | 3 mm | Brass | Push-Pull | 2.5 mm | 0.098 in | Square | Board to Board Cable | 0.197 in | 5 mm | Unshrouded | 0.169 " | 4.3 mm | 2 | Nylon Polyamide (PA) | 39.4 µin | 1 µm | Tin | |||||||
Hirose Electric Co Ltd | Black | Right Angle Through Hole | Male Pin | 250 V | Solder | Header | -55 C | 85 °C | UL94 V-0 | All | 1 | 0.118 in | 3 mm | Brass | Push-Pull | 2.5 mm | 0.098 in | Square | Board to Board Cable | 0.197 in | 5 mm | Unshrouded | 0.169 " | 4.3 mm | Nylon Polyamide (PA) | |||||||||||
 Hirose Electric Co Ltd | Black | Right Angle Through Hole | Male Pin | 250 V | Solder | Header | -55 C | 85 °C | UL94 V-0 | All | 1 | 0.118 in | 3 mm | Brass | Push-Pull | 2.5 mm | 0.098 in | Square | Board to Board Cable | 0.197 in | 5 mm | Unshrouded | 0.169 " | 4.3 mm | Nylon Polyamide (PA) | Gold | ||||||||||
Hirose Electric Co Ltd | Black | Right Angle Through Hole | Male Pin | 250 V | Solder | Header | -55 C | 85 °C | UL94 V-0 | All | 1 | 0.118 in | 3 mm | Brass | Push-Pull | 2.5 mm | 0.098 in | Square | Board to Board Cable | 0.197 in | 5 mm | Unshrouded | 0.169 " | 4.3 mm | 10 | Nylon Polyamide (PA) | Gold | |||||||||
 Hirose Electric Co Ltd | 15.5 mm | Black | Through Hole | Male Pin | 250 V | Solder | Header | -55 C | 85 °C | UL94 V-0 | All | 1 | 0.118 in | 3 mm | Brass | Push-Pull | 2.5 mm | 0.098 in | Square | Board to Board Cable | 0.197 in | 5 mm | Unshrouded | 0.256 in | 6.5 mm | 0.433 in | 11 mm | 2 | Nylon Polyamide (PA) | Gold | 8 µin | 0.203 µm | ||||
Hirose Electric Co Ltd | Contacts Not Included | |||||||||||||||||||||||||||||||||||
 Hirose Electric Co Ltd | 15.5 mm | Black | Through Hole | Male Pin | 250 V | Solder | Header | -55 C | 85 °C | UL94 V-0 | All | 1 | 0.118 in | 3 mm | Brass | Push-Pull | 2.5 mm | 0.098 in | Square | Board to Board Cable | 0.197 in | 5 mm | Unshrouded | 0.256 in | 6.5 mm | 0.433 in | 11 mm | 7 | Nylon Polyamide (PA) | 39.4 µin | 1 µm | |||||
Hirose Electric Co Ltd |
