89033 Series

Catalog

CABLE 3COND 12AWG WHITE 250'

Part	Jacket Color	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Voltage	Length	Length	Conductor Insulation	Conductor Insulation	Jacket (Insulation) Material	Wire Gauge	Operating Temperature [Min]	Operating Temperature [Max]	Cable Type	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Number of Conductors	Conductor Material	Features	Conductor Strand [custom]	Conductor Strand [custom]	Length [x]	Length [x]	Usage
Prysmian Group 89033.35.02	White	0.03 in	0.762 mm	300 VDC	76.2 m	250 ft	TPE	Thermoplastic Elastomer	Thermoplastic Elastomer (TPE)	12 AWG	-50 °C	105 ░C	Multi-Conductor	0.443 in	11.25 mm	3	Copper Bare	Oil Resistant	30 AWG	65
Prysmian Group 89033.35.01	Black	0.03 in	0.762 mm	300 VDC	3.05 m 15.24 m 76.2 m	10 ft 50 ft 250 ft	TPE	Thermoplastic Elastomer	Thermoplastic Elastomer (TPE)	12 AWG	-50 °C	105 ░C	Multi-Conductor	0.443 in	11.25 mm	3	Copper Bare	Oil Resistant	30 AWG	65	7.62 m 30.5 m	25 ft 100 ft	Cord and Cordset
Prysmian Group 89033.XX.02	White	0.03 in	0.762 mm	300 VDC			TPE	Thermoplastic Elastomer	Thermoplastic Elastomer (TPE)	12 AWG	-50 °C	105 ░C	Multi-Conductor	0.443 in	11.25 mm	3	Copper Annealed Bare	Oil Resistant	30 AWG	65
Prysmian Group 89033.41.01	Black	0.03 in	0.762 mm	300 VDC	304.8 m	1000 ft	TPE	Thermoplastic Elastomer	Thermoplastic Elastomer (TPE)	12 AWG	-50 °C	105 ░C	Multi-Conductor	0.443 in	11.25 mm	3	Copper Annealed Bare	Oil Resistant	30 AWG	65
Prysmian Group 89033.35.01	Black	0.03 in	0.762 mm	300 VDC	3.05 m 15.24 m 76.2 m	10 ft 50 ft 250 ft	TPE	Thermoplastic Elastomer	Thermoplastic Elastomer (TPE)	12 AWG	-50 °C	105 ░C	Multi-Conductor	0.443 in	11.25 mm	3	Copper Bare	Oil Resistant	30 AWG	65	7.62 m 30.5 m	25 ft 100 ft	Cord and Cordset
Prysmian Group 89033.46.02	White	0.03 in	0.762 mm	300 VDC			TPE	Thermoplastic Elastomer	Thermoplastic Elastomer (TPE)	12 AWG	-50 °C	105 ░C	Multi-Conductor	0.443 in	11.25 mm	3	Copper Annealed Bare	Oil Resistant	30 AWG	65
Prysmian Group 89033.35.02	White	0.03 in	0.762 mm	300 VDC	76.2 m	250 ft	TPE	Thermoplastic Elastomer	Thermoplastic Elastomer (TPE)	12 AWG	-50 °C	105 ░C	Multi-Conductor	0.443 in	11.25 mm	3	Copper Bare	Oil Resistant	30 AWG	65
Prysmian Group 89033.41.01	Black	0.03 in	0.762 mm	300 VDC	304.8 m	1000 ft	TPE	Thermoplastic Elastomer	Thermoplastic Elastomer (TPE)	12 AWG	-50 °C	105 ░C	Multi-Conductor	0.443 in	11.25 mm	3	Copper Annealed Bare	Oil Resistant	30 AWG	65
Prysmian Group 89033.41.02	White	0.03 in	0.762 mm	300 VDC	304.8 m	1000 ft	TPE	Thermoplastic Elastomer	Thermoplastic Elastomer (TPE)	12 AWG	-50 °C	105 ░C	Multi-Conductor	0.443 in	11.25 mm	3	Copper Annealed Bare	Oil Resistant	30 AWG	65
Prysmian Group 89033.41.02	White	0.03 in	0.762 mm	300 VDC	304.8 m	1000 ft	TPE	Thermoplastic Elastomer	Thermoplastic Elastomer (TPE)	12 AWG	-50 °C	105 ░C	Multi-Conductor	0.443 in	11.25 mm	3	Copper Annealed Bare	Oil Resistant	30 AWG	65
