TIM 2 Series

Catalog

MODULE DC-DC 24VIN 2-OUT -15V/15V 0.067A/0.067A 2W 7-PIN DIP MODULE

Part	Voltage - Output 2	Mounting Type	Current - Output (Max)	Current - Output (Max)	Voltage - Isolation	Features	Voltage - Output 1	Package / Case	Number of Outputs	Power (Watts)	Voltage - Input (Min) [Min]	Type	Voltage - Input (Max) [Max]	Operating Temperature [Max]	Operating Temperature [Min]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [z]	Applications	Efficiency	Current - Output (Max) [Max]
Traco Power TIM 2-2423	-15 V	Through Hole	67 mA	67 mA	5000 V	OVP Remote On/Off SCP	15 V	16-DIP Module 7 Leads	2	2 W	18 V	Isolated Module	36 V	95 °C	-40 °C	0.57 "	24.3 mm	0.96 "	10.2 mm	14.4 mm	0.4 "	Medical
Traco Power TIM 2-1223SM	-15 V	Surface Mount	67 mA	67 mA	5000 V	OVP Remote On/Off SCP	15 V	16-SMD Module 7 Leads	2	2 W	9 V	Isolated Module	18 V	95 °C	-40 °C	0.57 "	24.3 mm	0.96 "	10.2 mm	14.4 mm	0.4 "	Medical
Traco Power TIM 2-4812SM		Surface Mount			5000 V	OVP Remote On/Off SCP	12 V	16-SMD Module 7 Leads	1	2 W	36 V	Isolated Module	75 V	95 °C	-40 °C	0.57 "	24.3 mm	0.96 "	10.2 mm	14.4 mm	0.4 "	Medical	80 %	167 mA
Traco Power TIM 2-0922	-12 V	Through Hole	83 mA	83 mA	5000 V	OVP Remote On/Off SCP	12 V	16-DIP Module 7 Leads	2	2 W	4.5 V	Isolated Module	12 V	95 °C	-40 °C	0.57 "	24.3 mm	0.96 "	10.2 mm	14.4 mm	0.4 "	Medical	81 %
Traco Power TIM 2-2419		Through Hole			5000 V	OVP Remote On/Off SCP	9 V	16-DIP Module 7 Leads	1	2 W	18 V	Isolated Module	36 V	95 °C	-40 °C	0.57 "	24.3 mm	0.96 "	10.2 mm	14.4 mm	0.4 "	Medical	78 %	222 mA
Traco Power TIM 2-4819SM		Surface Mount			5000 V	OVP Remote On/Off SCP	9 V	16-SMD Module 7 Leads	1	2 W	36 V	Isolated Module	75 V	95 °C	-40 °C	0.57 "	24.3 mm	0.96 "	10.2 mm	14.4 mm	0.4 "	Medical	78 %	222 mA
Traco Power TIM 2-0922SM	-12 V	Surface Mount	83 mA	83 mA	5000 V	OVP Remote On/Off SCP	12 V	16-SMD Module 7 Leads	2	2 W	4.5 V	Isolated Module	12 V	95 °C	-40 °C	0.57 "	24.3 mm	0.96 "	10.2 mm	14.4 mm	0.4 "	Medical	81 %
Traco Power TIM 2-1222SM	-12 V	Surface Mount	83 mA	83 mA	5000 V	OVP Remote On/Off SCP	12 V	16-SMD Module 7 Leads	2	2 W	9 V	Isolated Module	18 V	95 °C	-40 °C	0.57 "	24.3 mm	0.96 "	10.2 mm	14.4 mm	0.4 "	Medical	81 %
Traco Power TIM 2-1215		Through Hole			5000 V	OVP Remote On/Off SCP	24 V	16-DIP Module 7 Leads	1	2 W	9 V	Isolated Module	18 V	95 °C	-40 °C	0.57 "	24.3 mm	0.96 "	10.2 mm	14.4 mm	0.4 "	Medical	81 %	83 mA
Traco Power TIM 2-4811SM		Surface Mount			5000 V	OVP Remote On/Off SCP	5 V	16-SMD Module 7 Leads	1	2 W	36 V	Isolated Module	75 V	95 °C	-40 °C	0.57 "	24.3 mm	0.96 "	10.2 mm	14.4 mm	0.4 "	Medical	77 %	400 mA
