E2202S Series
Manufacturer: Prysmian Group
Beta
⌘K
CABLE 2COND 18AWG GREEN SHLD
| Part | Conductor Strand [custom] | Conductor Strand [custom] | Number of Conductors | Cable Type | Usage | Jacket (Insulation) Material | Shield Type | Operating Temperature [Max] | Operating Temperature [Min] | Jacket Color | Wire Gauge | Jacket (Insulation) Thickness [x] | Jacket (Insulation) Thickness [x] | Conductor Insulation | Conductor Material | Features | Length | Length | Voltage | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Length [x] | Length [x] | Shield Material | Shield Coverage |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Prysmian Group | 26 AWG | 7 | 2 | Multi-Conductor | Alarm Security Sound | Plenum Poly-Vinyl Chloride (PVC) | Foil | 75 ░C | 0 °C | Green | 18 AWG | 0.381 mm | 0.015 in | Poly-Vinyl Chloride (PVC) | Copper Bare | Drain Wire | 304.8 m | 1000 ft | 300 VDC | 4.17 mm | 0.164 in | ||||
 Prysmian Group | 26 AWG | 7 | 2 | Multi-Conductor | Alarm Security Sound | Plenum Poly-Vinyl Chloride (PVC) | Foil | 75 ░C | 0 °C | White | 18 AWG | 0.381 mm | 0.015 in | Poly-Vinyl Chloride (PVC) | Copper Bare | Drain Wire | 15.24 m 304.8 m | 50 ft 1000 ft | 300 VDC | 4.17 mm | 0.164 in | 7.62 m 30.5 m | 25 ft 100 ft | ||
Prysmian Group | 26 AWG | 7 | 2 | Multi-Conductor | Alarm Security Sound | Plenum Poly-Vinyl Chloride (PVC) | Foil | 75 ░C | 0 °C | White | 18 AWG | 0.381 mm | 0.015 in | Poly-Vinyl Chloride (PVC) | Copper Bare | Drain Wire | 15.24 m 304.8 m | 50 ft 1000 ft | 300 VDC | 4.17 mm | 0.164 in | 7.62 m 30.5 m | 25 ft 100 ft | Flexfoil® | 100 % |
Prysmian Group | 26 AWG | 7 | 2 | Multi-Conductor | Alarm Security Sound | Plenum Poly-Vinyl Chloride (PVC) | Foil | 75 ░C | 0 °C | Purple | 18 AWG | 0.381 mm | 0.015 in | Poly-Vinyl Chloride (PVC) | Copper Bare | Drain Wire | 304.8 m | 1000 ft | 300 VDC | 4.17 mm | 0.164 in | Flexfoil® | 100 % | ||
 Prysmian Group | 26 AWG | 7 | 2 | Multi-Conductor | Alarm Security Sound | Plenum Poly-Vinyl Chloride (PVC) | Foil | 75 ░C | 0 °C | Natural | 18 AWG | 0.381 mm | 0.015 in | Poly-Vinyl Chloride (PVC) | Copper Bare | Drain Wire | 15.24 m 304.8 m | 50 ft 1000 ft | 300 VDC | 4.17 mm | 0.164 in | 30.5 m | 100 ft | Flexfoil® | 100 % |
Prysmian Group | 26 AWG | 7 | 2 | Multi-Conductor | Alarm Security Sound | Plenum Poly-Vinyl Chloride (PVC) | Foil | 75 ░C | 0 °C | Natural | 18 AWG | 0.381 mm | 0.015 in | Poly-Vinyl Chloride (PVC) | Copper Bare | Drain Wire | 152.4 m | 500 ft | 300 VDC | 4.17 mm | 0.164 in | ||||
Prysmian Group | 26 AWG | 7 | 2 | Multi-Conductor | Alarm Security Sound | Plenum Poly-Vinyl Chloride (PVC) | Foil | 75 ░C | 0 °C | Natural | 18 AWG | 0.381 mm | 0.015 in | Poly-Vinyl Chloride (PVC) | Copper Bare | Drain Wire | 304.8 m | 1000 ft | 300 VDC | 4.17 mm | 0.164 in | Flexfoil® | 100 % | ||
Prysmian Group | 26 AWG | 7 | 2 | Multi-Conductor | Alarm Security Sound | Plenum Poly-Vinyl Chloride (PVC) | Foil | 75 ░C | 0 °C | Natural | 18 AWG | 0.381 mm | 0.015 in | Poly-Vinyl Chloride (PVC) | Copper Bare | Drain Wire | 152.4 m | 500 ft | 300 VDC | 4.17 mm | 0.164 in | Flexfoil® | 100 % | ||
Prysmian Group | 26 AWG | 7 | 2 | Multi-Conductor | Alarm Security Sound | Plenum Poly-Vinyl Chloride (PVC) | Foil | 75 ░C | 0 °C | White | 18 AWG | 0.381 mm | 0.015 in | Poly-Vinyl Chloride (PVC) | Copper Bare | Drain Wire | 304.8 m | 1000 ft | 300 VDC | 4.17 mm | 0.164 in | ||||
Prysmian Group | 26 AWG | 7 | 2 | Multi-Conductor | Plenum Poly-Vinyl Chloride (PVC) | Foil | 75 ░C | 0 °C | Pink | 18 AWG | 0.381 mm | 0.015 in | Poly-Vinyl Chloride (PVC) | Copper Bare | Drain Wire | 304.8 m | 1000 ft | 300 VDC | 4.17 mm | 0.164 in |
