Bipolar Module - Diode Y1-CU
Bipolar Module - Diode Y1-CU
| Part | Diode Configuration | Operating Temperature - Junction [Min] | Operating Temperature - Junction [Max] | Speed [Min] | Voltage - DC Reverse (Vr) (Max) [Max] | Current - Average Rectified (Io) (per Diode) | Package / Case | Current - Reverse Leakage @ Vr | Supplier Device Package | Mounting Type | Voltage - Forward (Vf) (Max) @ If [Max] | Technology |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 LITTELFUSE | 1 Pair Series Connection | -40 °C | 150 °C | 200 mA 500 ns | 1800 V | 270 A | Y1-CU | 30 mA | Y1-CU | Chassis Mount | 1.4 V | Standard |
 LITTELFUSE | 1 Pair Series Connection | -40 °C | 150 °C | 200 mA 500 ns | 270 A | Y1-CU | 30 mA | Y1-CU | Chassis Mount | 1.4 V | Standard | |
 LITTELFUSE | 1 Pair Series Connection | -40 °C | 150 °C | 200 mA 500 ns | 1.2 kV | 270 A | Y1-CU | 30 mA | Y1-CU | Chassis Mount | 1.4 V | Standard |
LITTELFUSE | 1 Pair Series Connection | -40 °C | 150 °C | 200 mA 500 ns | 2000 V | 270 A | Y1-CU | 30 mA | Y1-CU | Chassis Mount | 1.4 V | Standard |
 LITTELFUSE | 1 Pair Series Connection | -40 °C | 150 °C | 200 mA 500 ns | 2200 V | 270 A | Y1-CU | 30 mA | Y1-CU | Chassis Mount | 1.4 V | Standard |
 LITTELFUSE | 1 Pair Series Connection | -40 °C | 150 °C | 200 mA 500 ns | 1400 V | 270 A | Y1-CU | 30 mA | Y1-CU | Chassis Mount | 1.4 V | Standard |
