IAUC120 Series

Manufacturer: INFINEON

Catalog

IAUC120N04S6L012 IS AN AUTOMOTIVE MOSFET OFFERING 40V, N-CH, 1.2 MΩ MAX, SSO8 (5X6), OPTIMOS™-6 FOR HIGH EFFICIENCY AND RELIABILITY.

Part	Operating Temperature [Max]	Operating Temperature [Min]	Power Dissipation (Max)	Mounting Type	Grade	Current - Continuous Drain (Id) @ 25°C	Gate Charge (Qg) (Max) @ Vgs [Max]	Technology	Package / Case	Supplier Device Package	Rds On (Max) @ Id, Vgs	Vgs(th) (Max) @ Id	Input Capacitance (Ciss) (Max) @ Vds	Vgs (Max)	Qualification	Drive Voltage (Max Rds On, Min Rds On)	FET Type	Drain to Source Voltage (Vdss)	Input Capacitance (Ciss) (Max) @ Vds [Max]	Gate Charge (Qg) (Max) @ Vgs
INFINEON IAUC120N04S6L012ATMA1	175 °C	-55 °C	115 W	Surface Mount	Automotive	120 A	80 nC	MOSFET (Metal Oxide)	8-PowerTDFN	PG-TDSON-8	1.21 mOhm	2 V	4832 pF	16 V	AEC-Q101	4.5 V 10 V	N-Channel	40 V
INFINEON IAUC120N04S6N010ATMA1	175 °C	-55 °C	150 W	Surface Mount	Automotive	150 A	108 nC	MOSFET (Metal Oxide)	8-PowerTDFN	PG-TDSON-8-34	1.03 mOhm	3 V	6878 pF	20 V	AEC-Q101	7 V 10 V	N-Channel	40 V
INFINEON IAUC120N04S6L005ATMA1	175 °C	-55 °C	187 W	Surface Mount	Automotive	120 A	177 nC	MOSFET (Metal Oxide)	8-PowerTDFN	PG-TDSON-8-53		2 V		16 V	AEC-Q101	4.5 V 10 V	N-Channel	40 V	11203 pF
INFINEON IAUC120N04S6N006ATMA1	175 °C	-55 °C	187 W	Surface Mount	Automotive	120 A	151 nC	MOSFET (Metal Oxide)	8-PowerTDFN	PG-TDSON-8-53	0.6 mOhm	3 V		20 V	AEC-Q101	7 V 10 V	N-Channel	40 V	10117 pF
INFINEON IAUC120N06S5N017ATMA1	175 °C	-55 °C	167 W	Surface Mount	Automotive	120 A	95.9 nC	MOSFET (Metal Oxide)	8-PowerTDFN	PG-TDSON-8-43	1.7 mOhm	3.4 V		20 V	AEC-Q101		N-Channel	60 V	6952 pF
INFINEON IAUC120N04S6N013ATMA1	175 °C	-55 °C	115 W	Surface Mount	Automotive	120 A		MOSFET (Metal Oxide)	8-PowerTDFN	PG-TDSON-8	1.34 mOhm	3 V		20 V	AEC-Q101	7 V 10 V	N-Channel	40 V	4260 pF	68 nC
INFINEON IAUC120N04S6L009ATMA1	175 °C	-55 °C	150 W	Surface Mount	Automotive	150 A	128 nC	MOSFET (Metal Oxide)	8-PowerTDFN	PG-TDSON-8-34	960 mOhm	2 V		16 V	AEC-Q101	4.5 V 10 V	N-Channel	40 V	7806 pF
