AD8013 Series

Catalog

IC SINGLE SUPPLY OPAMP 14 DIP

Part	Current - Output / Channel	Mounting Type	Package / Case	Package / Case [y]	Package / Case [x]	-3db Bandwidth	Current - Supply	Number of Circuits	Slew Rate	Voltage - Supply, Single/Dual (±) [Min]	Voltage - Supply, Single/Dual (±) [Max]	Board Type	Supplied Contents	Channels per IC	Amplifier Type	Utilized IC / Part
Analog Devices AD8013AN	30 mA	Through Hole	14-DIP	7.62 mm	0.3 "	140 MHz	3.5 mA	3	1000 V/µs	-2.1 V 4.2 V	6.5 V 13 V
Analog Devices AD8013AR-14-REEL7	30 mA	Surface Mount	14-SOIC	3.9 mm	0.154 in	140 MHz	3.5 mA	3	1000 V/µs	-2.1 V 4.2 V	6.5 V 13 V
Analog Devices AD8013ARZ-14	30 mA	Surface Mount	14-SOIC	3.9 mm	0.154 in	140 MHz	3.5 mA	3	1000 V/µs	-2.1 V 4.2 V	6.5 V 13 V
Analog Devices AD8013ARZ-14-RL	30 mA	Surface Mount	14-SOIC	3.9 mm	0.154 in	140 MHz	3.5 mA	3	1000 V/µs	-2.1 V 4.2 V	6.5 V 13 V
Analog Devices AD8013AR-14	30 mA	Surface Mount	14-SOIC	3.9 mm	0.154 in	140 MHz	3.5 mA	3	1000 V/µs	-2.1 V 4.2 V	6.5 V 13 V
Analog Devices AD8013ANZ	30 mA	Through Hole	14-DIP	7.62 mm	0.3 "	140 MHz	3.5 mA	3	1000 V/µs	-2.1 V 4.2 V	6.5 V 13 V
Analog Devices AD8013ARZ-14-R7	30 mA	Surface Mount	14-SOIC	3.9 mm	0.154 in	140 MHz	3.5 mA	3	1000 V/µs	-2.1 V 4.2 V	6.5 V 13 V
Analog Devices AD8013AR-14-EBZ												Bare (Unpopulated)	Board(s)	3 - Triple	Current Feedback	8-SOIC Package
