BNC-P-1.5 Series
Manufacturer: Hirose Electric Co Ltd
Beta
⌘K
CONN RF COAX PLUG
| Part | Center Contact Plating | Body Material | Operating Temperature [Max] | Operating Temperature [Min] | Mating Cycles | Body Finish | Dielectric Material | Connector Type | Mounting Type | Frequency - Max [Max] | Cable Group | Shield Termination | Fastening Type | Impedance | Number of Ports | Connector Style | Center Contact Material | Housing Color | Contact Termination |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Hirose Electric Co Ltd | Gold | Brass | 85 °C | -40 C | 1000 | Nickel | Polytetrafluoroethylene (PTFE) | Plug Male Pin | Free Hanging (In-Line) | 4 GHz | 1.5D-2V 1.5D-HQEV 1.5D-QEV | Crimp | Bayonet Lock | 50 Ohms | 1 | BNC | Brass | Silver | Solder |
Hirose Electric Co Ltd | |||||||||||||||||||
Hirose Electric Co Ltd | |||||||||||||||||||
 Hirose Electric Co Ltd | Silver | Brass | 60 °C | -30 ░C | 1000 | Nickel | Polytetrafluoroethylene (PTFE) | Plug Male Pin | Free Hanging (In-Line) | 2 GHz | 1.5D-2V | Clamp | Bayonet Lock | 50 Ohms | 1 | BNC | Brass | Silver | Solder |
 Hirose Electric Co Ltd | Silver | Brass | 60 °C | -30 ░C | 1000 | Nickel | Polytetrafluoroethylene (PTFE) | Plug Male Pin | Free Hanging (In-Line) | 2 GHz | 1.5D-2W | Clamp | Bayonet Lock | 50 Ohms | 1 | BNC | Brass | Silver | Solder |
 Hirose Electric Co Ltd | Silver | Brass | 60 °C | -30 ░C | 1000 | Nickel | Polytetrafluoroethylene (PTFE) | Plug Male Pin | Free Hanging (In-Line) | 4 GHz | 1.5C-2W 1.5D-2W | Crimp | Bayonet Lock | 50 Ohms | 1 | BNC | Brass | Silver | Solder |
Hirose Electric Co Ltd | Gold | Brass | 85 °C | -40 C | 1000 | Nickel | Polytetrafluoroethylene (PTFE) | Plug Male Pin | Free Hanging (In-Line) | 1 GHz | 1.5D-HQEW | Crimp | Bayonet Lock | 50 Ohms | 1 | BNC | Brass | Silver | Solder |
