LMG5200 Series
Manufacturer: Texas Instruments
Beta
⌘K
EVAL BOARD FOR LMG5200
| Part | Utilized IC / Part | Contents | Type | Supplied Contents | Function | Secondary Attributes | Interface | Rds On (Typ) | Operating Temperature [Min] | Operating Temperature [Max] | Features | Package / Case | Mounting Type | Technology | Applications | Voltage - Supply [Min] | Voltage - Supply [Max] | Supplier Device Package | Voltage - Load | Load Type | Current - Output / Channel | Fault Protection |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Texas Instruments | LMG5200 | Board(s) | Power Management | Board(s) | Half H-Bridge Driver (Internal FET) | On-Board LEDs Test Points | ||||||||||||||||
Texas Instruments | Logic | 15 mOhm | -40 °C | 125 ¯C | Bootstrap Circuit | 9-QFN | Surface Mount | Gallium Nitride (GaN) FETs | Synchronous Buck Converters | 4.75 V | 5.25 V | 9-QFN (8x6) | 80 V | Inductive | 10 A | UVLO | ||||||
 Texas Instruments | Logic | 15 mOhm | -40 °C | 125 ¯C | Bootstrap Circuit | 9-QFN | Surface Mount | Gallium Nitride (GaN) FETs | Synchronous Buck Converters | 4.75 V | 5.25 V | 9-QFN (8x6) | 80 V | Inductive | 10 A | UVLO |
