TEL 5 Series
Manufacturer: Traco Power
Beta
⌘K
DC DC CONVERTER +/-15V 6W
| Part | Power (Watts) | Efficiency | Voltage - Isolation | Applications | Package / Case | Voltage - Input (Max) [Max] | Voltage - Output 1 | Number of Outputs | Features | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [x] | Mounting Type | Voltage - Output 2 | Type | Voltage - Input (Min) [Min] | Operating Temperature [Min] | Operating Temperature [Max] | Supplier Device Package | Current - Output (Max) [Max] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Traco Power | 6 W | 86 % | 1.5 kV | ITE (Commercial) | 23-DIP Module 8 Leads | 36 V | 15 V | 2 | SCP | 0.8 " | 0.4 " | 31.8 mm | 10.2 mm | 20.3 mm | 1.25 in | Through Hole | -15 V | Isolated Module | 18 V | -40 °C | 85 °C | Module | |
 Traco Power | 4 W | 77 % | 1.5 kV | ITE (Commercial) | 23-DIP Module 7 Leads | 18 V | 3.3 V | 1 | SCP | 0.8 " | 0.4 " | 31.8 mm | 10.2 mm | 20.3 mm | 1.25 in | Through Hole | Isolated Module | 9 V | -40 °C | 85 °C | Module | 1.2 A |
