09225SA Series
DC Fans DC Axial Fan, 92x92x25mm, 24VDC, 61.8CFM, Flange Mount, Ball, 3-Lead Wires, Tach
Manufacturer: NMB TECHNOLOGIES
Catalog
DC Fans DC Axial Fan, 92x92x25mm, 24VDC, 61.8CFM, Flange Mount, Ball, 3-Lead Wires, Tach
Beta
⌘K
DC Fans DC Axial Fan, 92x92x25mm, 24VDC, 61.8CFM, Flange Mount, Ball, 3-Lead Wires, Tach
DC Fans DC Axial Fan, 92x92x25mm, 24VDC, 61.8CFM, Flange Mount, Ball, 3-Lead Wires, Tach
DC Fans DC Axial Fan, 92x92x25mm, 24VDC, 61.8CFM, Flange Mount, Ball, 3-Lead Wires, Tach
| Part | Lifetime @ Temp. | Material - Frame | Material - Blade | Size / Dimension [y] | Size / Dimension [x] | Voltage - Rated | Width [y] | Bearing Type | Operating Temperature [Max] | Operating Temperature [Min] | Fan Type | Ingress Protection | Termination | Features | Voltage Range [Min] | Voltage Range [Max] | Air Flow | Air Flow | Current Rating (Amps) | Weight | Weight | RPM | Power (Watts) | Noise | Static Pressure | Static Pressure |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 NMB TECHNOLOGIES | 40000 Hrs | Plastic | Plastic | 92 mm | 92 mm | 24 VDC | 25 mm | Ball | 70 °C | -10 °C | Tubeaxial | IP55 - Dust Protected Water Resistant | 2 Wire Leads | |||||||||||||
 NMB TECHNOLOGIES | 92 mm | 92 mm | 12 VDC | 25 mm | Ball | Tubeaxial | 3 Wire Leads | Locked Rotor Sensor | ||||||||||||||||||
 NMB TECHNOLOGIES | 100000 Hrs | Plastic | Plastic | 92 mm | 92 mm | 24 VDC | 25 mm | Ball | 70 °C | -10 °C | Tubeaxial | 2 Wire Leads | 12 | 27.6 VDC | 48.4 CFM | 1.35 mł/min | 70 mA | 0.209 lb | 94.8 g | 2750 RPM | 1.56 W | 32 dB | 0.154 in H2O | 38.4 Pa | ||
 NMB TECHNOLOGIES | 92 mm | 92 mm | 12 VDC | 25 mm | Ball | Tubeaxial | 2 Wire Leads | |||||||||||||||||||
NMB TECHNOLOGIES | 92 mm | 92 mm | 24 VDC | 25 mm | Ball | Tubeaxial | 2 Wire Leads | |||||||||||||||||||
NMB TECHNOLOGIES | 100000 Hrs | Plastic | Plastic | 92 mm | 92 mm | 24 VDC | 25 mm | Ball | 70 °C | -10 °C | Tubeaxial | 2 Wire Leads | 12 | 27.6 VDC | 48.4 CFM | 1.35 mł/min | 70 mA | 0.209 lb | 94.8 g | 2750 RPM | 1.56 W | 32 dB | 0.154 in H2O | 38.4 Pa | ||
NMB TECHNOLOGIES | 92 mm | 92 mm | 24 VDC | 25 mm | Ball | Tubeaxial | 2 Wire Leads | |||||||||||||||||||
NMB TECHNOLOGIES | 92 mm | 92 mm | 12 VDC | 25 mm | Ball | Tubeaxial | 3 Wire Leads | Speed Sensor (Tach) | ||||||||||||||||||
 NMB TECHNOLOGIES | 100000 Hrs | Plastic | Plastic | 92 mm | 92 mm | 12 VDC | 25 mm | Ball | 70 °C | -10 °C | Tubeaxial | 2 Wire Leads | 6 VDC | 13.8 VDC | 41.3 CFM | 1.16 mł/min | 100 mA | 0.209 lb | 94.8 g | 2400 RPM | 1.2 W | 28 dB | 0.12 in H2O | 29.9 Pa | ||
 NMB TECHNOLOGIES | 92 mm | 92 mm | 24 VDC | 25 mm | Ball | 70 °C | -10 °C | Tubeaxial | 2 Wire Leads | Auto Restart | 65 CFM | 1.82 m³/min | 3900 RPM | 3.12 W | 40 dB(A) | 0.29 in H2O | 72.2 Pa |
