BYC5 Series

Catalog

DIODE GEN PURP 500V 5A TO220AC

Part	Operating Temperature - Junction [Max]	Voltage - DC Reverse (Vr) (Max) [Max]	Supplier Device Package	Current - Average Rectified (Io)	Current - Reverse Leakage @ Vr	Speed	Mounting Type	Voltage - Forward (Vf) (Max) @ If	Reverse Recovery Time (trr)	Technology	Package / Case	Voltage - Forward (Vf) (Max) @ If [Max]	Operating Temperature - Junction [Min]
WeEn Semiconductors BYC5-600,127	150 °C	500 V	TO-220AC	5 A	100 µA	200 mA 500 ns	Through Hole	2.9 V	50 ns	Standard	TO-220-2
WeEn Semiconductors BYC5X-600PQ	175 ░C	600 V	TO-220F	5 A	10 µA	200 mA 500 ns	Through Hole		25 ns	Standard	TO-220-2 Full Pack Isolated Tab	3.3 V	-65 C
WeEn Semiconductors BYC5DX-500,127	150 °C	500 V	TO-220FP	5 A	40 µA	200 mA 500 ns	Through Hole	2 V	16 ns	Standard	TO-220-2 Full Pack Isolated Tab
WeEn Semiconductors BYC5-1200PQ	175 ░C	1.2 kV	TO-220AC	5 A	100 µA	200 mA 500 ns	Through Hole	3.2 V	36 ns	Standard	TO-220-2
WeEn Semiconductors BYC5X-600,127	150 °C	500 V	TO-220FP	5 A	100 µA	200 mA 500 ns	Through Hole	2.9 V	50 ns	Standard	TO-220-2 Full Pack Isolated Tab
WeEn Semiconductors BYC5D-500,127	150 °C	500 V	TO-220AC	5 A	40 µA	200 mA 500 ns	Through Hole	2 V	16 ns	Standard	TO-220-2
WeEn Semiconductors BYC5B-600,118	150 °C	500 V	D2PAK	5 A	100 µA	200 mA 500 ns	Surface Mount	2.9 V	50 ns	Standard	D2PAK (2 Leads + Tab) TO-263-3 TO-263AB
WeEn Semiconductors BYC5-600PQ	175 ░C	600 V	TO-220AC	5 A	10 µA	200 mA 500 ns	Through Hole		25 ns	Standard	TO-220-2	3.3 V	-65 C
