PSMN1R0-40SSH Series

N-channel 40 V, 1 mΩ, 325 Amps continuous, standard level MOSFET in LFPAK88 using NextPowerS3 Technology

Catalog

N-channel 40 V, 1 mΩ, 325 Amps continuous, standard level MOSFET in LFPAK88 using NextPowerS3 Technology

Part	Vgs (Max)	Vgs(th) (Max) @ Id	Drain to Source Voltage (Vdss)	FET Feature	Drive Voltage (Max Rds On, Min Rds On)	Power Dissipation (Max)	Current - Continuous Drain (Id) @ 25°C	Rds On (Max) @ Id, Vgs	Technology	FET Type	Supplier Device Package	Operating Temperature [Max]	Operating Temperature [Min]	Gate Charge (Qg) (Max) @ Vgs [Max]	Mounting Type	Package / Case	Input Capacitance (Ciss) (Max) @ Vds
Nexperia USA Inc. PSMN1R0-40SSHJ	20 V	3.6 V	40 V	Schottky Diode (Body)	10 V	375 W	325 A	1 mOhm	MOSFET (Metal Oxide)	N-Channel	LFPAK88 (SOT1235)	175 °C	-55 °C	137 nC	Surface Mount	SOT-1235	10322 pF

Catalog

N-channel 40 V, 1 mΩ, 325 Amps continuous, standard level MOSFET in LFPAK88 using NextPowerS3 Technology

Description

325 Amp continuous current, standard level gate drive, N-channel enhancement mode MOSFET in LFPAK88 package. NextPowerS3 family using Nexperia’s unique "SchottkyPlus" technology delivers high efficiency and low spiking performance usually associated with MOSFETs with an integrated Schottky or Schottky-like diode but without problematic high leakage current. NextPowerS3 is particularly suited to high efficiency applications at high switching frequencies, and also safe and reliable switching at high load-current.
