DSA1001 Series

Catalog

MEMS OSCILLATOR, AUTOMOTIVE, CMO

Part	Current - Supply (Disable) (Max) [Max]	Operating Temperature [Min]	Operating Temperature [Max]	Ratings	Frequency Stability	Package / Case	Base Resonator	Mounting Type	Output	Frequency	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Type	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Current - Supply (Max) [Max]	Function	Voltage - Supply [Max]	Voltage - Supply [Min]
Microchip Technology DSA1001DL3-012.2888TVAO	15 µA	-40 °C	105 ░C	AEC-Q100	20 ppm	4-VDFN	MEMS	Surface Mount	CMOS	12.2888 MHz	0.035 "	0.9 mm	XO (Standard)	0.098 "	2 mm	2.5 mm	0.079 in	8 mA	Standby (Power Down)	3.6 V	1.7 V
Microchip Technology DSA1001DI2-025.0000VAO	15 µA	-40 °C	85 °C	AEC-Q100	25 ppm	4-VDFN	MEMS	Surface Mount	CMOS	25 MHz	0.035 "	0.9 mm	XO (Standard)	0.098 "	2 mm	2.5 mm	0.079 in	8 mA	Standby (Power Down)	3.6 V	1.7 V
Microchip Technology DSA1001DL1-125.0000VAO	15 µA	-40 °C	105 ░C	AEC-Q100	50 ppm	4-VDFN	MEMS	Surface Mount	CMOS	125 MHz	0.035 "	0.9 mm	XO (Standard)	0.098 "	2 mm	2.5 mm	0.079 in	8 mA	Standby (Power Down)	3.6 V	1.7 V
Microchip Technology DSA1001DL2-020.0000TVAO	15 µA	-40 °C	105 ░C	AEC-Q100	25 ppm	4-VDFN	MEMS	Surface Mount	CMOS	20 MHz	0.035 "	0.9 mm	XO (Standard)	0.098 "	2 mm	2.5 mm	0.079 in	8 mA	Standby (Power Down)	3.6 V	1.7 V
Microchip Technology DSA1001DI3-020.0000VAO	15 µA	-40 °C	85 °C	AEC-Q100	20 ppm	4-VDFN	MEMS	Surface Mount	CMOS	20 MHz	0.035 "	0.9 mm	XO (Standard)	0.098 "	2 mm	2.5 mm	0.079 in	8 mA	Standby (Power Down)	3.6 V	1.7 V
Microchip Technology DSA1001DL2-020.0000VAO	15 µA	-40 °C	105 ░C	AEC-Q100	25 ppm	4-VDFN	MEMS	Surface Mount	CMOS	20 MHz	0.035 "	0.9 mm	XO (Standard)	0.098 "	2 mm	2.5 mm	0.079 in	8 mA	Standby (Power Down)	3.6 V	1.7 V
Microchip Technology DSA1001DL1-074.2500TVAO	15 µA	-40 °C	105 ░C	AEC-Q100	50 ppm	4-VDFN	MEMS	Surface Mount	CMOS	74.25 MHz	0.035 "	0.9 mm	XO (Standard)	0.098 "	2 mm	2.5 mm	0.079 in	10.5 mA	Standby (Power Down)	3.6 V	1.7 V
Microchip Technology DSA1001DL1-100.0000TVAO	15 µA	-40 °C	105 ░C	AEC-Q100	50 ppm	4-VDFN	MEMS	Surface Mount	CMOS	100 MHz	0.035 "	0.9 mm	XO (Standard)	0.098 "	2 mm	2.5 mm	0.079 in	8 mA	Standby (Power Down)	3.6 V	1.7 V
Microchip Technology DSA1001DL2-025.0000VAO	15 µA	-40 °C	105 ░C	AEC-Q100	25 ppm	4-VDFN	MEMS	Surface Mount	CMOS	25 MHz	0.035 "	0.9 mm	XO (Standard)	0.098 "	2 mm	2.5 mm	0.079 in	8 mA	Standby (Power Down)	3.6 V	1.7 V
Microchip Technology DSA1001DL3-024.0000TVAO	15 µA	-40 °C	105 ░C	AEC-Q100	20 ppm	4-VDFN	MEMS	Surface Mount	CMOS	24 MHz	0.035 "	0.9 mm	XO (Standard)	0.098 "	2 mm	2.5 mm	0.079 in	8 mA	Standby (Power Down)	3.6 V	1.7 V
